LTC3113EDHD#TRPBF Transistor ADE Chip Reg BCK BST ADJ 3A 16DFN
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | LTC3113EDHD#TRPBF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Product Status: | Active | Function: | Step-Up/Step-Down |
|---|---|---|---|
| Output Configuration: | Positive | Topology: | Buck-Boost |
| Output Type: | Adjustable | Number Of Outputs: | 1 |
| Voltage - Input (Min): | 1.8V | Voltage - Input (Max): | 5.5V |
| High Light: | LTC3113EDHD#TRPBF,Transistor ADE Chip,3A 16DFN ic Chip |
||
Product Description
LTC3113EDHD#TRPBF Transistor Ic Chip Reg Bck Bst Adj 3a 16dfn
Buck-Boost Switching Regulator IC Positive Adjustable 1.8V 1 Output 3A 16-WFDFN Exposed Pad
Specifications of LTC3113EDHD#TRPBF
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Regulators - DC DC Switching Regulators | |
| Mfr | Analog Devices Inc. |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Function | Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Buck-Boost |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 1.8V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1.8V |
| Voltage - Output (Max) | 5.5V |
| Current - Output | 3A |
| Frequency - Switching | 300kHz ~ 2MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 16-WFDFN Exposed Pad |
| Supplier Device Package | 16-DFN (5x4) |
| Base Product Number | LTC3113 |
Features of LTC3113EDHD#TRPBF
• Regulated Output with Input Voltage Above, Below or Equal to the Output Voltage
• 1.8V to 5.5V Input and Output Voltage Range
• 3A Continuous Output Current VIN > 3.0V, VOUT =3.8V
• 1.5A Continuous Output Current for VIN ≥ 1.8V,VOUT = 3.3V
• Single Inductor
• Low Noise Buck-Boost Architecture
• Up to 96% Effi ciency
• Programmable Frequency from 300kHz to 2MHz
• Selectable Burst Mode® Operation
• Output Disconnect in Shutdown
• Shutdown Current: <1μA
• Internal Soft-Start
• Small, Thermally Enhanced 16-Lead (4mm × 5mm × 0.75mm) DFN Package and 20-Lead TSSOP Package
Applications of LTC3113EDHD#TRPBF
Environmental & Export Classifications of LTC3113EDHD#TRPBF
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
