DMN5L06DWK7 Transistor IC MOSFET Dual N Channel 2 Channel Small Signal
Product Details:
| Place of Origin: | Original |
| Brand Name: | Original |
| Certification: | Original |
| Model Number: | DMN5L06DWK7 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Mounting Style:: | SMD/SMT | Transistor Polarity:: | N-Channel |
|---|---|---|---|
| Packaging:: | Cut Tape | Package / Case:: | SOT-363-6 |
| Number Of Channels:: | 2 Channel | Product Type:: | MOSFET |
| High Light: | Transistor IC DMN5L06DWK7,MOSFET Dual N Channel 2 Channel,Small Signal Transistor IC |
||
Product Description
DMN5L06DWK7 Transistor IC MOSFET Dual N Channel 2 Channel Small Signal
DMN5L06DWK7 Transistor IC Chip MOSFET Dual N Channel 2 Channel Small Signals
Features of DMN5L06DWK7
Dual N-Channel MOSFET
Low On-Resistance (1.0V Max)
Very Low Gate Threshold Voltage
Low Input Capacitance
Fast Switching Speed
Low Input/Output Leakage
Ultra-Small Surface Mount Package
ESD Protected up to 2kV
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliabilit
Mechanical Data of DMN5L06DWK7
| Case | SOT363 |
| Case Material | Molded Plastic, “Green” Molding Compound. UL Flammability Classification Rating 94V-0 |
| Moisture Sensitivity | Level 1 per J-STD-020 |
| Terminal Connections | See Diagram |
| Terminals | Finish – Matte Tin Annealed over Alloy 42 Leadframe. Solderable per MIL-STD-202, Method 208 |
| Weight | 0.006 grams (Approximate) |
Product Attributes of DMN5L06DWK7
|
Technology
|
MOSFET (Metal Oxide)
|
|
Configuration
|
2 N-Channel (Dual)
|
|
FET Feature
|
Logic Level Gate
|
|
Drain to Source Voltage (Vdss)
|
50V
|
|
Current - Continuous Drain (Id) @ 25°C
|
305mA
|
|
Rds On (Max) @ Id, Vgs
|
2Ohm @ 50mA, 5V
|
|
Vgs(th) (Max) @ Id
|
1V @ 250µA
|
|
Gate Charge (Qg) (Max) @ Vgs
|
-
|
|
Input Capacitance (Ciss) (Max) @ Vds
|
50pF @ 25V
|
|
Power - Max
|
250mW
|
|
Operating Temperature
|
-65°C ~ 150°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
6-TSSOP, SC-88, SOT-363
|
|
Supplier Device Package
|
SOT-363
|
|
Base Product Number
|
DMN5L06
|
In warehouse.
