MCIMX515DJM8C Microprocessor IC With 1 Core 32-Bit 800MHz 529-BGA (19x19)
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SPC5605BK0VLU6R |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Core Processor: | ARM® Cortex®-A8 | Number Of Cores/Bus Width: | 1 Core, 32-Bit |
|---|---|---|---|
| Speed: | 800MHz | Co-Processors/DSP: | Multimedia; NEON™ SIMD |
| RAM Controllers: | LPDDR, DDR2 | Display & Interface Controllers: | Keypad, LCD |
| Ethernet: | 10/100Mbps (1) | USB: | USB 2.0 (3), USB 2.0 + PHY (1) |
| High Light: | MCIMX515DJM8C Microprocessor IC,Microprocessor IC With 1 Core |
||
Product Description
MCIMX515DJM8C Microprocessor IC With 1 Core, 32-Bit 800MHz 529-BGA (19x19)
MCIMX515DJM8C ARM® Cortex®-A8 Microprocessor IC i.MX51 1 Core, 32-Bit 800MHz 529-BGA (19x19)
Specifications of MCIMX515DJM8C
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Microprocessors | |
| Series | i.MX51 |
| Package | Tray |
| Product Status | Active |
| Core Processor | ARM® Cortex®-A8 |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Speed | 800MHz |
| Co-Processors/DSP | Multimedia; NEON™ SIMD |
| RAM Controllers | LPDDR, DDR2 |
| Graphics Acceleration | Yes |
| Display & Interface Controllers | Keypad, LCD |
| Ethernet | 10/100Mbps (1) |
| SATA | - |
| USB | USB 2.0 (3), USB 2.0 + PHY (1) |
| Voltage - I/O | 1.2V, 1.875V, 2.775V, 3.0V |
| Operating Temperature | -20°C ~ 85°C (TC) |
| Security Features | ARM TZ, Boot Security, Cryptography, RTIC, Secure Fusebox, Secure JTAG, Secure Memory, Secure RTC |
| Mounting Type | Surface Mount |
| Package / Case | 529-LFBGA |
| Supplier Device Package | 529-BGA (19x19) |
| Additional Interfaces | 1-Wire, AC'97, I²C, I²S, MMC/SD, SPI, SSI, UART |
| Base Product Number | MCIMX515 |
Features of MCIMX515DJM8C
• Up to 40 Mhz CPI at 3.6V to 2.1V
• Up to 20 MHz CPU at 2.1V to 1.8V across temperature range of -40°C to +85°C
• Two ultra-low-power stop modes, one of which allows limited use of peripherals
• New low-power run and wait modes
• 6 μs typical wake-up time from stop mode
• Internal clock source (ICS) module containing a frequencylocked loop (FLL) controlled by internal or external reference
• Ultra-low-power oscillator (OSC)
• Clock gating disables clocks to unused peripherals
Applications of MCIMX515DJM8C
• Single-phase electricity meters
• Low-end utility metering
• Portable medical equipment
• Thermostats
• Automated test equipment
• Industrial process control and measurement
• Sensor interfacing
• Digital scales
Environmental & Export Classifications of MCIMX515DJM8C
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | 5A992C |
| HTSUS | 8542.31.0001 |
