IGBT 600V 15A 56W DPAK IC STGD6NC60HDT4 PowerMESH Surface Mount
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | STGD6NC60HDT4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Voltage - Collector Emitter Breakdown (Max): | 600 V | Current - Collector (Ic) (Max): | 15 A |
|---|---|---|---|
| Current - Collector Pulsed (Icm): | 21 A | Vce(on) (Max) @ Vge, Ic: | 2.5V @ 15V, 3A |
| Power - Max: | 56 W | Switching Energy: | 20µJ (on), 68µJ (off) |
| Input Type: | Standard | Gate Charge: | 13.6 NC |
| High Light: | DPAK IC STGD6NC60HDT4,IGBT 600V 15A 56W DPAK IC,600V 15A 56W DPAK IC |
||
Product Description
STGD6NC60HDT4 Current Sense Resistors Igbt 600v 15a 56w Dpak
IGBT 600 V 15 A 56 W Surface Mount DPAK
Specifications of STGD6NC60HDT4
| TYPE | DESCRIPTION |
| Category | Discrete Semiconductor Products |
| Transistors | |
| IGBTs | |
| Single IGBTs | |
| Mfr | STMicroelectronics |
| Series | PowerMESH™ |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 15 A |
| Current - Collector Pulsed (Icm) | 21 A |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 3A |
| Power - Max | 56 W |
| Switching Energy | 20µJ (on), 68µJ (off) |
| Input Type | Standard |
| Gate Charge | 13.6 nC |
| Td (on/off) @ 25°C | 12ns/76ns |
| Test Condition | 390V, 3A, 10Ohm, 15V |
| Reverse Recovery Time (trr) | 21 ns |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Supplier Device Package | DPAK |
| Base Product Number | STGD6 |
Features of STGD6NC60HDT4
■ Low on voltage drop (Vcesat)
■ Low CRES / CIES ratio (no cross-conduction susceptibility)
■ Very soft ultra fast recovery antiparallel diode
■ High frequency operation
Applications of STGD6NC60HDT4
■ High frequency inverters
■ SMPS and PFC in both hard switch and
resonant topologies
■ Motor drivers
Environmental & Export Classifications of STGD6NC60HDT4
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.29.0095 |
