TPD4E05U06DQAR Dip Ic Sockets Tvs Diode 5.5vwm 14vc 10uson 6 Weeks
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | TPD4E05U06DQAR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Product Status: | Active | Type: | Steering (Rail To Rail) |
|---|---|---|---|
| Unidirectional Channels: | 4 | Voltage - Reverse Standoff (Typ): | 5.5V (Max) |
| Voltage - Breakdown (Min): | 6V | Voltage - Clamping (Max) @ Ipp: | 14V |
| Power - Peak Pulse: | 2.5A (8/20µs) | Product Status Active Type Steering (Rail To Rail) Unidirectional Channels 4 Voltage - Reverse Stand: | 40W |
Product Description
TPD4E05U06DQAR Dip Ic Sockets Tvs Diode 5.5vwm 14vc 10uson 6 Weeks
14V Clamp 2.5A (8/20µs) Ipp Tvs Diode Surface Mount 10-USON (2.5x1)
Specifications of TPD4E05U06DQAR
| TYPE | DESCRIPTION |
| Category | Circuit Protection |
| Transient Voltage Suppressors (TVS) | |
| TVS Diodes | |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Type | Steering (Rail to Rail) |
| Unidirectional Channels | 4 |
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
| Voltage - Breakdown (Min) | 6V |
| Voltage - Clamping (Max) @ Ipp | 14V |
| Current - Peak Pulse (10/1000µs) | 2.5A (8/20µs) |
| Power - Peak Pulse | 40W |
| Power Line Protection | Yes |
| Applications | HDMI |
| Capacitance @ Frequency | - |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 10-UFDFN |
| Supplier Device Package | 10-USON (2.5x1) |
| Base Product Number | TPD4E05U06 |
Features of TPD4E05U06DQAR
• IEC 61000-4-2 level 4 ESD protection
– ±12-kV contact discharge
– ±15-kV air gap discharge
• IEC 61000-4-4 EFT protection
– 80 A (5/50 ns)
• IEC 61000-4-5 surge protection
– 2.5 A (8/20 µs)
• IO capacitance 0.42 pF to 0.5 pF (typical)
• DC breakdown voltage 6.5 V (minimum)
• Ultra low leakage current 10 nA (maximum)
• Low ESD clamping voltage
• Industrial temperature range: –40°C to +125°C
• Easy straight-through routing packages
• Industry standard SOD-523 package (1.60 mm × 0.80 mm × 0.65 mm)
Applications of TPD4E05U06DQAR
• HDMI 1.4b
• HDMI 2.0
• USB 3.0
• MHL
• LVDS interfaces
• DisplayPort
• PCI-express®
• eSata interfaces
• V-by-One® HS
Environmental & Export Classifications of TPD4E05U06DQAR
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.10.0080 |
