TPS63802DLAR Dip Ic Sockets Ic Power Management 296-Tps63802dlardkr-Nd



Buck-Boost Switching Regulator IC Positive Adjustable 1.8V 1 Output 2A 10-VFDFN



Specifications of TPS63802DLAR



TYPE DESCRIPTION
Category Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - DC DC Switching Regulators
Mfr Texas Instruments
Series -
Package Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
Product Status Active
Function Step-Up/Step-Down
Output Configuration Positive
Topology Buck-Boost
Output Type Adjustable
Number of Outputs 1
Voltage - Input (Min) 1.3V
Voltage - Input (Max) 5.5V
Voltage - Output (Min/Fixed) 1.8V
Voltage - Output (Max) 5.2V
Current - Output 2A
Frequency - Switching 2.1MHz
Synchronous Rectifier Yes
Operating Temperature -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 10-VFDFN
Supplier Device Package 10-VSON-HR (3x2)
Base Product Number TPS63802



Features of TPS63802DLAR


• Input voltage range: 1.3V to 5.5 V
– Device input voltage >1.8 V for start-up
• Output voltage range: 1.8 V to 5.2 V (adjustable)
• 2-A output current forVI≥ 2.3 V, VO = 3.3 V
• High efficiency over theentire load range
– 11-µA operatingquiescent current
– Power save mode andmode selection forforced PWM-mode
• Peak current buck-boostmode architecture
– Defined transitionpoints between buck,buckboost, and boostoperation modes
– Forward and reversecurrent operation
– Start-up into pre-biased outputs
• Safety and robustoperation features
– Integrated soft start
– Overtemperature- andovervoltage-protection
– True shutdown functionwith load disconnect
– Forward and backwardcurrent limit
• Small solution size of21.5 mm2
– Tiny SON/DFN package(similar to QFN)
– Small 0.47-µH inductor
– Works with a 22-µFminimum output capacitor
• Create a custom designusing the TPS63802 withthe WEBENCH® PowerDesigner




Applications of TPS63802DLAR


• System pre-regulator (tracking and telematics, portable POS, home automation, IP network camera)
• Point-of-load regulation(wired sensor, port/cable adapter and dongle, electronic smart lock, IoT)
• Battery back-up supply (electricity meter, data concentrator, power quality meter)
• Thermoelectric device supply (TEC, optical modules)
• General purpose voltage stabilizer and converter





Environmental & Export Classifications of TPS63802DLAR



ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
