1.24V 6V 15mA Power Management ICs TLV431BQDBZR SOT23-3
Product Details:
| Place of Origin: | Original |
| Brand Name: | Original |
| Certification: | Original |
| Model Number: | TLV431BQDBZR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Output Type: | Adjustable | Voltage - Output (Min/Fixed): | 1.24V |
|---|---|---|---|
| Voltage - Output (Max): | 6 V | Current - Output: | 15 MA |
| Tolerance: | ±0.5% | Current - Cathode: | 100 µA |
| High Light: | 15mA Power Management ICs,1.24V 6V Power Management ICs,TLV431BQDBZR |
||
Product Description
TLV431BQDBZR Power Management ICs VREF SHUNT ADJ 0.5% SOT23-3 1.24V 6V 15 mA
The TLV431 device is a low-voltage 3-terminal adjustable voltage reference with specified thermal
stability over applicable industrial and commercial temperature ranges.
Specifications of TLV431BQDBZR
|
TYPE
|
DESCRIPTION
|
|---|---|
|
Category
|
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Reference
|
|
Mfr
|
Texas Instruments
|
|
Series
|
-
|
|
Product
|
TLV431BQDBZR
|
|
Reference Type
|
Shunt
|
|
Output Type
|
Adjustable
|
|
Voltage - Output (Min/Fixed)
|
1.24V
|
|
Voltage - Output (Max)
|
6 V
|
|
Current - Output
|
15 mA
|
|
Tolerance
|
±0.5%
|
|
Temperature Coefficient
|
-
|
|
Noise - 0.1Hz to 10Hz
|
-
|
|
Noise - 10Hz to 10kHz
|
-
|
|
Voltage - Input
|
-
|
|
Current - Supply
|
-
|
|
Current - Cathode
|
100 µA
|
|
Operating Temperature
|
-40°C ~ 125°C (TA)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
TO-236-3, SC-59, SOT-23-3
|
|
Supplier Device Package
|
SOT-23-3
|
|
Base Product Number
|
TLV431
|
Features of TLV431BQDBZR
• Low-Voltage Operation, VREF = 1.24 V
• Adjustable Output Voltage, VO = VREF to 6 V
• Reference Voltage Tolerances at 25°C
– 0.5% for TLV431B
– 1% for TLV431A
– 1.5% for TLV431
• Typical Temperature Drift
– 4 mV (0°C to 70°C)
– 6 mV (–40°C to 85°C)
– 11 mV (–40°C to 125°C)
• Low Operational Cathode Current, 80 µA Typical
• 0.25-Ω Typical Output Impedance
• Ultra-Small SC-70 Package Offers 40% Smaller
Footprint Than SOT-23-3
• See TLVH431 and TLVH432 for:
– Wider VKA (1.24 V to 18 V) and IK (80 mA)
– Additional SOT-89 Package
– Multiple Pinouts for SOT-23-3 and SOT-89 Packages
• On Products Compliant to MIL-PRF-38535, All Parameters Are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Necessarily Include Testing of All Parameters.
applications of TLV431BQDBZR
• Adjustable Voltage and Current Referencing
• Secondary Side Regulation in Flyback SMPSs
• Zener Replacement
• Voltage Monitoring
• Comparator With Integrated Reference
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
