SPC5602PEF0MLH6R Current Sense Resistors Ic Mcu 32bit 256kb Flash 64lqfp
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SPC5602PEF0MLH6R |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Peripherals: | DMA, POR, PWM, WDT | Number Of I/O: | 45 |
|---|---|---|---|
| Program Memory Size: | 256KB (256K X 8) | Program Memory Type: | FLASH |
| EEPROM Size: | 4K X 16 | RAM Size: | 20K X 8 |
| Voltage - Supply (Vcc/Vdd): | 3V ~ 5.5V | Data Converters: | A/D 16x10b |
Product Description
SPC5602PEF0MLH6R Current Sense Resistors Ic Mcu 32bit 256kb Flash 64lqfp
e200z0h MPC56xx Qorivva Microcontroller IC 32-Bit Single-Core 64MHz 256KB (256K x 8) FLASH 64-LQFP (10x10)
Specifications of SPC5602PEF0MLH6R
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Embedded | |
| Microcontrollers | |
| Mfr | NXP USA Inc. |
| Series | MPC56xx Qorivva |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| Digi-Key Programmable | Not Verified |
| Core Processor | e200z0h |
| Core Size | 32-Bit Single-Core |
| Speed | 64MHz |
| Connectivity | CANbus, LINbus, SCI, SPI |
| Peripherals | DMA, POR, PWM, WDT |
| Number of I/O | 45 |
| Program Memory Size | 256KB (256K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 16 |
| RAM Size | 20K x 8 |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Data Converters | A/D 16x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 64-LQFP |
| Supplier Device Package | 64-LQFP (10x10) |
| Base Product Number | SPC5602 |
Features of SPC5602PEF0MLH6R
• Up to 64 MHz, single issue, 32-bit CPU core complex (e200z0h)
— Compliant with Power Architecture embedded category
— Variable Length Encoding (VLE)
• Memory organization
— Up to 256 KB on-chip code flash memory with ECC and erase/program controller
— Optional: additional 64 (4 × 16) KB on-chip data flash memory with ECC for EEPROM emulation
— Up to 20 KB on-chip SRAM with ECC
• Fail-safe protection
— Programmable watchdog timer
— Non-maskable interrupt
— Fault collection unit
• Nexus Class 1 interface
• Interrupts and events
— 16-channel eDMA controller
— 16 priority level controller
— Up to 25 external interrupts
— PIT implements four 32-bit timers
— 120 interrupts are routed via INTC
• General purpose I/Os
— Individually programmable as input, output or special function
— 37 on 64 LQFP
— 64 on 100 LQFP
• 1 general purpose eTimer unit
— 6 timers each with up/down capabilities
— 16-bit resolution, cascadeable counters
— Quadrature decode with rotation direction flag
— Double buffer input capture and output compare
• Communications interfaces
— Up to 2 LINFlex modules (1× Master/Slave, 1× Master only)
— Up to 3 DSPI channels with automatic chip select generation (up to 8/4/4 chip selects)
Applications of SPC5602PEF0MLH6R
• One 10-bit analog-to-digital converter (ADC)
— Up to 16 input channels (16 ch on 100 LQFP and 12 ch on 64 LQFP)
— Conversion time < 1 µs including sampling time at full precision
— Programmable Cross Triggering Unit (CTU)
— 4 analog watchdogs with interrupt capability
Environmental & Export Classifications of SPC5602PEF0MLH6R
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | 3A991A2 |
| HTSUS | 8542.31.0001 |
