SN65176BDR Current Sense Resistors Sop-8 Rs-485/Rs-422 Ics Rohs
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SN65176BDR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Product Status: | Active | Type: | Transceiver |
|---|---|---|---|
| Protocol: | RS422, RS485 | Number Of Drivers/Receivers: | 1/1 |
| Duplex: | Half | Receiver Hysteresis: | 70 MV |
| Voltage - Supply: | 4.75V ~ 5.25V | Operating Temperature: | -40°C ~ 105°C (TA) |
Product Description
SN65176BDR Current Sense Resistors Sop-8 Rs-485/Rs-422 Ics Rohs
1/1 Transceiver Half RS422, RS485 8-SOP
Specifications of SN65176BDR
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Drivers, Receivers, Transceivers | |
| Mfr | UMW |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Type | Transceiver |
| Protocol | RS422, RS485 |
| Number of Drivers/Receivers | 1/1 |
| Duplex | Half |
| Receiver Hysteresis | 70 mV |
| Data Rate | - |
| Voltage - Supply | 4.75V ~ 5.25V |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOP |
Features of SN65176BDR
• Meets EIA Standard RS485 for Multipoint Bus Transmission and is Compatible with RS-422.
• Small Outline (SOIC) Package Option Available for Minimum Board Space.
•22 ns Driver Propagation Delays.
• Single +5V Supply.
•−7V to +12V Bus Common Mode Range Permits ±7V Ground Difference Between Devices on the Bus.
• Thermal Shutdown Protection.
• High Impedance to Bus with Driver in TRI STATE or with Power Off, Over the Entire Common Mode Range Allows the Unused Devices on the Bus to be Powered Down.
• Combined Impedance of a Driver Output and Receiver Input is Less Than One RS485 Unit Load, Allowing up to 32 Transceivers on the Bus.
• 70 mV Typical Receiver Hysteresis.
Applications of SN65176BDR
The SN75176B / SN65176B is a high speed differential TRI-STATE bus/line transceiver designed to meet the ® requirements of EIA standard RS485 with extended common mode range (+12V to −7V), for multipoint data transmission. In addition, it is compatible with
RS-422. The driver and receiver outputs feature TRI-STATE capability, for the driver outputs over the entire common mode range of +12V to −7V. Bus contention or fault situations that cause excessive power dissipation within the device are handled by a thermal shutdown circuit, which forces the driver outputs into the high impedance state. DC specifications are guaranteed over the 0 to 70°C temperature and 4.75V to 5.25V supply voltage range.
Environmental & Export Classifications of SN65176BDR
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
