TMS320F2812ZHHA Temperature Sensor Chip 32BIT 256KB 179BGA IC MCU
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | TMS320F2812ZHHA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Mfr: | Texas Instruments | Series: | Automotive, AEC-Q100, C2000™ C28x Fixed-Point |
|---|---|---|---|
| Package: | Tray | Product Status: | Obsolete |
| Core Processor: | C28x | Core Size: | 32-Bit Single-Core |
| Speed: | 150MHz | Connectivity: | CANbus, EBI/EMI, McBSP, SCI, SPI, UART/USART |
| High Light: | TMS320F2812ZHHA,32BIT 256KB 179BGA IC MCU,MCU Temperature Sensor Chip |
||
Product Description
TMS320F2812ZHHA Integrated Circuits IC Mcu 32bit 256kb Flash 179bga
TMS320F2812ZHHA Controller Integrated Circuits IC Mcu 32bit 256kb Flash 179bga
C28x Automotive, AEC-Q100, C2000™ C28x Fixed-Point Microcontroller IC 32-Bit Single-Core 150MHz 256KB (128K x 16) FLASH 179-BGA MicroStar (12x12)
Specifications of TMS320F2812ZHHA
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Embedded | |
| Microcontrollers | |
| Mfr | Texas Instruments |
| Series | Automotive, AEC-Q100, C2000™ C28x Fixed-Point |
| Package | Tray |
| Product Status | Obsolete |
| Core Processor | C28x |
| Core Size | 32-Bit Single-Core |
| Speed | 150MHz |
| Connectivity | CANbus, EBI/EMI, McBSP, SCI, SPI, UART/USART |
| Peripherals | DMA, POR, PWM, WDT |
| Number of I/O | 56 |
| Program Memory Size | 256KB (128K x 16) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 18K x 16 |
| Voltage - Supply (Vcc/Vdd) | 1.81V ~ 2V |
| Data Converters | A/D 16x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 179-LFBGA |
| Supplier Device Package | 179-BGA MicroStar (12x12) |
| Base Product Number | TMS320 |
Features of TMS320F2812ZHHA
• High-Performance Static CMOS Technology
- 150 MHz(6.67-ns Cycle Time)
-Low-Power(1.8-VCoreat135MHz,
1.9-V Core at 150 MHz,3.3-V I/O)Design
• JTAG Boundary Scan Support
• High-Performance 32-Bit CPU(TMS320C28xTM)
-16x16and32x32MACOperations
-16x16DualMAC
-Harvard Bus Architecture
-Atomic Operations
-Fast Interrupt Response and Processing
-Unified Memory Programming Model
-4M Linear Program/Data Address Reach
-Code-Efficient (in C/C++ and Assembly)
-TMS320F24x/LF240x Processor Source Code Compatible
• On-Chip Memory
-Flash Devices: Up to 128K x 16 Flash
(Four 8K x 16 and Six 16K 16 Sectors)-ROM Devices:Up to 128K x 16 • ROM - 1Kx 16 OTP ROM
• L0 and L1:2 Blocks of 4K 16 Each Single-Access RAM (SARAM)
-H0:1Block of 8K 16 SARAM
- M0 and M1:2 Blocks of 1K 16 Each SARAM
• Boot ROM(4Kx x 16)
-With Software Boot Modes
- Standard Math Tables
• External Interface(2812)
-Over 1Mx 16 Total Memory
- Programmable Wait States
-Programmable Read/Write Strobe Timing
-Three Individual Chip Selects
• Endianness:Little Endian
APPLICATIONS of TMS320F2812ZHHA
• Clock and System Control
-Dynamic PLL Ratio Changes Supported
-On-Chip Oscillator
-Watchdog Timer Module
• Three External Interrupts
• Peripheral Interrupt Expansion (PIE)Block That Supports 45 Peripheral Interrupts
• Three 32-Bit CPU-Timers
• 128-Bit Security Key/Lock
-Protects Flash/ROM/OTP and L0/L1 SARAM -Prevents Firmware Reverse-Engineering
• Motor Control Peripherals
- Two Event Managers(EVA,EVB)
- Compatible to 240xA Devices
• Serial Port Peripherals
- Serial Peripheral Interface(SPI)
-Two Serial Communications Interfaces (SCls),Standard UART
-Enhanced Controller Area Network(eCAN)
- Multichannel Buffered Serial Port (McBSP)
• 12-Bit ADC,16 Channels
-2x8Channel Input Multiplexer
-Two Sample-and-Hold
- Single/Simultaneous Conversions
-Fast Conversion Rate:80 ns/12.5 MSPS
• Up to 56 General-Purpose I/O (GPIO) Pins • Advanced Emulation Features
-Analysis and Breakpoint Functions
- Real-Time Debug via Hardware
• Development Tools Include
- ANSI C/C++ Compiler/Assembler/Linker
- Code Composer Studio TM IDE
- DSP/BIOSTM
-JTAG Scan Controllers(1)
• Low-Power Modes and Power Savings
-IDLE,STANDBY,HALT Modes Supported
- Disable Individual Peripheral Clocks
Environmental & Export Classifications of TMS320F2812ZHHA
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | 3A991A2 |
| HTSUS | 8542.31.0001 |
