1.5A TPS57160QDGQRQ1 Temperature Sensor Chip 10-MSOP 10-PowerTFSOP
Product Details:
| Place of Origin: | Original |
| Brand Name: | Original |
| Certification: | Original |
| Model Number: | TPS57160QDGQRQ1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Part Number: | TPS57160QDGQRQ1 | Number Of Outputs: | 1 |
|---|---|---|---|
| Voltage - Input (Min): | 3.5V | Voltage - Input (Max): | 60V |
| Voltage - Output (Min/Fixed): | 0.8V | Voltage - Output (Max): | 58V |
| Current - Output: | 1.5A | Frequency - Switching: | 100kHz ~ 2.5MHz |
| High Light: | 1.5A TPS57160QDGQRQ1,Temperature Sensor Chip 10-MSOP,TPS57160QDGQRQ1 Temperature Sensor Chip |
||
Product Description
TPS57160QDGQRQ1 Temperature Sensor Chip 1.5A 10-PowerTFSOP, 10-MSOP
The TPS57160-Q1 device is a 60-V 1.5-A step-down regulator with an integrated high-side MOSFET.
Current-mode control provides simple external compensation and flexible component selection.
A low-ripple pulse-skip mode reduces the no load, input supply current to 116 μA. Using the enable pin,
shutdown supply current is reduced to 1.5 μA.
Features of TPS57160QDGQRQ1
Qualified for Automotive Applications
3.5-V to 60-V Input Voltage Range
200-mQ High-Side MOSFET
High Efficiency at Light Loads With Pulse
-Skipping Eco-modeTM Control Scheme
116-μA Operating Quiescent Current
1.5-uA Shutdown Current
100-kHz to 2.5-MHz Switching Frequency
Synchronizes to External Clock
Adjustable Slow Start/Sequencing
Undervoltage and Overvoltage Power-good Output Adjustable Undervoltage Lockout (UVLO)Voltage and Hysteresis
0.8-V Internal Voltage Reference
Supported by SwitcherProTM Software Tool
Z-Suffix Offers Improved Delamination
Specifications of TPS57160QDGQRQ1
|
Product
|
TPS57160QDGQRQ1
|
|
Function
|
Step-Down
|
|
Output Configuration
|
Positive
|
|
Topology
|
Buck
|
|
Output Type
|
Adjustable
|
|
Number of Outputs
|
1
|
|
Voltage - Input (Min)
|
3.5V
|
|
Voltage - Input (Max)
|
60V
|
|
Voltage - Output (Min/Fixed)
|
0.8V
|
|
Voltage - Output (Max)
|
58V
|
|
Current - Output
|
1.5A
|
|
Frequency - Switching
|
100kHz ~ 2.5MHz
|
|
Synchronous Rectifier
|
No
|
|
Operating Temperature
|
-40°C ~ 125°C (TA)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
10-PowerTFSOP, 10-MSOP (0.118", 3.00mm Width)
|
|
Supplier Device Package
|
10-HVSSOP
|
|
Base Product Number
|
TPS57160
|
Applications of TPS57160QDGQRQ1
• 12-V, 24-V, and 48-V Industrial and Commercial Low-Power Systems
• Aftermarket Automotive Accessories: Video, GPS, Entertainment
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
