Multi Chemistry Charger IC 20VQFN 12.6V Surface Mount IC BQ24130RHLR
Product Details:
| Place of Origin: | Original |
| Brand Name: | Original |
| Certification: | Original |
| Model Number: | BQ24130RHLR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Part Number: | BQ24130RHLR | Number Of Cells: | 1 ~ 3 |
|---|---|---|---|
| Battery Pack Voltage: | 12.6V | Voltage - Supply (Max): | 17V |
| Operating Temperature: | -40°C ~ 85°C (TA) | Mounting Type: | Surface Mount |
| Supplier Device Package: | 20-VQFN (3.5x4.5) | Interface: | - |
| High Light: | Multi Chemistry Charger IC,Charger IC 20VQFN,12.6V BQ24130RHLR |
||
Product Description
BQ24130RHLR SMD LED Chip Charger IC Multi-Chemistry 20-VQFN 12.6V
Charger IC Multi-Chemistry 20-VQFN (3.5x4.5) IC BAT CHG MULTCHEM 1-3CL
The BQ2409x series of devices are highly integrated Li-ion and Li-Pol linear chargers devices targete at space-limited portable applications.
Features of BQ24130RHLR
600kHz Synchronous Switch-mode Charger with 4 A Integrated N-MOSFETs
Up to 96% Efficiency
30 V Input Rating with 18V Overvoltage Protection
- 4.5 V to 17 V Input Operating Range Battery Charge Voltage - 1,2,or 3-Cell With 4.2V/Cell
Constant Current Super Capacitor Charging
High Integration
- Integrated 20-V Switching MOSFETs
- Integrated Bootstrap Diode
- Internal Loop Compensation Internal Digital Soft Start
Safety
Thermal Regulation Loop Throttles Back Current to Limit Tj=120°C Thermal Shutdown
- Battery Thermistor Sense Hot/Cold Charge Suspend
- Input Overvoltage Protection
- Cycle by Cycle Current Limit
Accuracy
- ±0.5% Charge Voltage Regulation
- ±4% Charge Current Regulation
Less than 15 μA Battery Current with Adapter Removed
Product Attributes of BQ24130RHLR
|
Mfr
|
Texas Instruments
|
|
Series
|
-
|
|
Product
|
BQ24130RHLR
|
|
Battery Chemistry
|
Multi-Chemistry
|
|
Number of Cells
|
1 ~ 3
|
|
Current - Charging
|
Constant - Programmable
|
|
Programmable Features
|
-
|
|
Fault Protection
|
Over Temperature, Over Voltage
|
|
Charge Current - Max
|
-
|
|
Battery Pack Voltage
|
12.6V
|
|
Voltage - Supply (Max)
|
17V
|
|
Interface
|
-
|
|
Operating Temperature
|
-40°C ~ 85°C (TA)
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
20-VFQFN Exposed Pad
|
|
Supplier Device Package
|
20-VQFN (3.5x4.5)
|
|
Base Product Number
|
BQ24130
|
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
Applications of BQ24130RHLR
· Netbook and Ultra-Mobile Computers
· Portable Data Capture Terminals
· Portable Printers
· Medical Diagnostics Equipment
· Battery Bay Chargers
· Back-Up Systems
· Li-lon/Li-Polymer Battery and Super Capacitor Applications
