CY7C68013A-128AXC IC MCU USB PERIPH HI SPD 128LQFP 3V ~ 3.6V I²C
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | CY7C68013A-128AXC |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Core Processor: | 8051 | Program Memory Type: | ROMless |
|---|---|---|---|
| RAM Size: | 16K X 8 | Interface: | I²C, USB, USART |
| Number Of I/O: | 40 | Voltage - Supply: | 3V ~ 3.6V |
Product Description
CY7C68013A-128AXC IC MCU USB PERIPH HI SPD 128LQFP 3V ~ 3.6V I²C
Specifications of CY7C68013A-128AXC
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Embedded | |
| Application Specific Microcontrollers | |
| Mfr | Infineon Technologies |
| Series | EZ-USB FX2LP™ |
| Package | Tray |
| Applications | USB Microcontroller |
| Core Processor | 8051 |
| Program Memory Type | ROMless |
| Controller Series | CY7C680xx |
| RAM Size | 16K x 8 |
| Interface | I²C, USB, USART |
| Number of I/O | 40 |
| Voltage - Supply | 3V ~ 3.6V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Package / Case | 128-LQFP |
| Supplier Device Package | 128-TQFP (14x20) |
| Base Product Number | CY7C68013 |
Features of CY7C68013A-128AXC
■ USB 2.0 USB IF Hi-Speed certified (TID # 40460272)
■ Single-chip integrated USB 2.0 transceiver, smart SIE, and enhanced 8051 microprocessor
■ Fit-, form-, and function-compatible with the FX2
❐ Pin-compatible0
❐ Object-code-compatible
❐ Functionally compatible (FX2LP is a superset)
■ Ultra-low power: ICC no more than 85 mA in any mode
❐ Ideal for bus- and battery-powered applications
■ Software: 8051 code runs from:
❐ Internal RAM, which is downloaded through USB
❐ Internal RAM, which is loaded from EEPROM
❐ External memory device (128-pin package)
■ 16 KB of on-chip code/data RAM
■ Four programmable BULK, INTERRUPT, and ISOCHRONOUS endpoints
❐ Buffering options: Double, triple, and quad
■ Additional programmable (BULK/INTERRUPT) 64-byte endpoint
■ 8-bit or 16-bit external data interface
■ Smart media standard ECC generation
■ GPIF™ (general programmable interface)
❐ Enables direct connection to most parallel interfaces
❐ Programmable waveform descriptors and configuration registers to define waveforms
❐ Supports multiple ready (RDY) inputs and control (CTL) outputs
■ Integrated, industry-standard, enhanced 8051
❐ 48-MHz, 24-MHz, or 12-MHz CPU operation
❐ Four clocks per instruction cycle
❐ Two USARTs
❐ Three counter/timers
❐ Expanded interrupt system
❐ Two data pointers
■ 3.3-V operation with 5-V tolerant inputs
■ Vectored USB interrupts and GPIF/FIFO interrupts
■ Separate data buffers for the setup and data portions of a CONTROL transfer
■ Integrated I2C controller; runs at 100 or 400 kHz[1]
■ Four integrated FIFOs
❐ Integrated glue logic and FIFOs lower system cost
❐ Automatic conversion to and from 16-bit buses
❐ Master or slave operation
❐ Uses external clock or asynchronous strobes
❐ Easy interface to ASIC and DSP ICs
■ Available in commercial and industrial temperature grades (all packages except VFBGA)
Applications of CY7C68013A-128AXC
■ Portable video recorder
■ MPEG/TV conversion
■ DSL modems
■ ATA interface
■ Memory card readers
■ Legacy conversion devices
■ Cameras
■ Scanners
■ Wireless LAN
■ MP3 players
■ Networking
