LMK00334RTVT PCI Express (PCIe), SATA CPU IC 400MHz 1 Output 32-WQFN (5x5)
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | LMK00334RTVT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Main Purpose: | PCI Express (PCIe), SATA CPU | Input: | CML, HCSL, HSTL, LVDS, LVPECL, SSTL, Crystal |
|---|---|---|---|
| Output: | HCSL, LVCMOS | Number Of Circuits: | 1 |
| Ratio - Input:Output: | 3:05 | Frequency - Max: | 400MHz |
| Voltage - Supply: | 3.15V ~ 3.45V | ||
Product Description
SN74CBTLV3257DBQR Multiplexer/Demultiplexer 4 x 1:2 16-SSOP
Specifications of LMK00334RTVT
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Clock/Timing | |
| Application Specific Clock/Timing | |
| Mfr | Texas Instruments |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Key Programmable | Not Verified |
| PLL | No |
| Main Purpose | PCI Express (PCIe), SATA CPU |
| Input | CML, HCSL, HSTL, LVDS, LVPECL, SSTL, Crystal |
| Output | HCSL, LVCMOS |
| Number of Circuits | 1 |
| Ratio - Input:Output | 3:05 |
| Differential - Input:Output | Yes/Yes |
| Frequency - Max | 400MHz |
| Voltage - Supply | 3.15V ~ 3.45V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 32-WFQFN Exposed Pad |
| Supplier Device Package | 32-WQFN (5x5) |
| Base Product Number | LMK00334 |
Features of LMK00334RTVT
• 3:1 Input multiplexer
– Two universal inputs operate up to 400 MHz
and accept LVPECL, LVDS, CML, SSTL, HSTL,
HCSL, or single-ended clocks
– One crystal input accepts a 10- to 40-MHz
crystal or single-ended clock
• Two banks with two differential outputs each
– HCSL, or Hi-Z (selectable)
– Additive RMS phase jitter for PCIe Gen5 at 100
MHz:
• 15 fs RMS (typical)
• High PSRR: –72 dBc at 156.25 MHz
• LVCMOS output with synchronous enable input
• Pin-controlled configuration
• VCC core supply: 3.3 V ± 5%
• Three independent VCCO output supplies: 3.3 V,
2.5 V ± 5%
• Industrial temperature range: –40°C to +105°C
• 32-pin WQFN (5 mm × 5 mm)
Application of LMK00334RTVT
• Data center switches
• Core routers
• Servers, computing, PCIe Gen 3.0 to 5.0
• Remote radio units and baseband units
