ATMEGA1609-MUR Administrator: ATMEGA1609-MUR IC MCU 8BIT 16KB FLASH 48UQFN
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | ATMEGA1609-MUR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Core Processor: | AVR | Core Size: | 8-Bit |
|---|---|---|---|
| Speed: | 20MHz | Connectivity: | I²C, SPI, UART/USART |
| Peripherals: | Brown-out Detect/Reset, POR, PWM, WDT | Number Of I/O: | 41 |
| Program Memory Size: | 16KB (16K X 8) | Program Memory Type: | FLASH |
Product Description
ATMEGA1609-MUR Administrator: ATMEGA1609-MUR IC MCU 8BIT 16KB FLASH 48UQFN
AVR megaAVR® 0, Functional Safety (FuSa) Microcontroller IC 8-Bit 20MHz 16KB (16K x 8) FLASH 48-UQFN (6x6)
Specifications of ATMEGA1609-MUR
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Embedded | |
| Microcontrollers | |
| Mfr | Microchip Technology |
| Series | megaAVR® 0, Functional Safety (FuSa) |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Core Processor | AVR |
| Core Size | 8-Bit |
| Speed | 20MHz |
| Connectivity | I²C, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 41 |
| Program Memory Size | 16KB (16K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 256 x 8 |
| RAM Size | 2K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 5.5V |
| Data Converters | A/D 16x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 48-UFQFN Exposed Pad |
| Supplier Device Package | 48-UQFN (6x6) |
| Base Product Number | ATMEGA1609 |
Features of ATMEGA1609-MUR
• AVR® CPU:
– Single-cycle I/O access
– Two-level interrupt controller
– Two-cycle hardware multiplier
• Memories:
– 8 or 16 KB In-system self-programmable Flash memory
– 256B EEPROM
– 2 KB SRAM
– Write/Erase endurance:
• Flash 10,000 cycles
• EEPROM 100,000 cycles
– Data retention: 40 years at 55°C
• System:
– Power-on Reset (POR) circuit
– Brown-out Detector (BOD)
– Clock options:
• 16/20 MHz low-power internal oscillator
• 32.768 kHz Ultra Low-Power (ULP) internal oscillator
• 32.768 kHz external crystal oscillator
• External clock input
– Single-pin Unified Program Debug Interface (UPDI)
– Three sleep modes:
• Idle with all peripherals running for immediate wake-up
• Standby
– Configurable operation of selected peripherals
– SleepWalking peripherals
• Power-Down with limited wake-up functionality
• Peripherals:
– One 16-bit Timer/Counter type A (TCA) with a dedicated period register and three compare channels
– Up to four 16-bit Timer/Counters type B (TCB) with input capture
– One 16-bit Real-Time Counter (RTC) running from an external crystal or an internal RC oscillator
– Up to four USARTs with fractional baud rate generator, auto-baud, and start-of-frame detection
– Master/slave Serial Peripheral Interface (SPI)
– Master/slave TWI with dual address match
• Can operate simultaneously as master and slave
• Standard mode (Sm, 100 kHz)
• Fast mode (Fm, 400 kHz)
• Fast mode plus (Fm+, 1 MHz)
– Event System for core independent and predictable inter-peripheral signaling
– Configurable Custom Logic (CCL) with up to four programmable Look-up Tables (LUT)
– One Analog Comparator (AC) with a scalable reference input
– One 10-bit 150 ksps Analog-to-Digital Converter (ADC)
– Five selectable internal voltage references: 0.55V, 1.1V, 1.5V, 2.5V, and 4.3V
– CRC code memory scan hardware
• Optional automatic CRC scan before code execution is allowed
– Watchdog Timer (WDT) with Window mode, with a separate on-chip oscillator
– External interrupt on all general purpose pins
Applications of ATMEGA1609-MUR
The ATmega808/809/1608/1609 microcontrollers are part of the megaAVR® 0-series, which uses the AVR®
Environmental & Export Classifications of ATMEGA1609-MUR
| ATTRIBUTE DESCRIPTION | |
| RoHS Status ROHS3 Compliant | |
| REACH Status REACH Unaffected | |
| ECCN EAR99 | |
| HTSUS 8542.31.0001 |
