SN65HVD10D 1/1 Transceiver Electronic IC Chips Half RS422, RS485 8-SOIC
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SN65HVD10D |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Protocol: | RS422, RS485 | Number Of Drivers/Receivers: | 1/1 |
|---|---|---|---|
| Duplex: | Half | Receiver Hysteresis: | 35 MV |
| Data Rate: | 32Mbps | Voltage - Supply: | 3V ~ 3.6V |
| Operating Temperature: | -40°C ~ 85°C | Mounting Type: | Surface Mount |
Product Description
SN65HVD10D 1/1 Transceiver Electronic IC Chips Half RS422, RS485 8-SOIC
Specifications of SN65HVD10D
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Drivers, Receivers, Transceivers | |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tube |
| Type | Transceiver |
| Protocol | RS422, RS485 |
| Number of Drivers/Receivers | 1/1 |
| Duplex | Half |
| Receiver Hysteresis | 35 mV |
| Data Rate | 32Mbps |
| Voltage - Supply | 3V ~ 3.6V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | 65HVD10 |
Features of SN65HVD10D
• Operates with a 3.3-V supply
• Bus-pin ESD protection exceeds 16-kV HBM
• 1/8 Unit-load option available (up to 256 nodes on the bus)
• Optional driver output transition times for signaling rates 1of 1 Mbps, 10 Mbps, and 32 Mbps
• Meets or exceeds the requirements of ANSI TIA/ EIA-485-A
• Bus-pin short-circuit protection from –7 V to 12 V
• Low-current standby mode: 1 µA, typical
• Open-circuit, idle-bus, and shorted-bus fail-safe receiver
• Thermal shutdown protection
• Glitch-free power-up and power-down protection for hot-plugging applications
• SN75176 footprint
Applications of SN65HVD10D
Digital motor control
• Utility meters
• Chassis-to-chassis interconnects
• Electronic security stations
• Industrial process control
• Building automation
• Point-of-sale (POS) terminals and networks
Environmental & Export Classifications of SN65HVD10D
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | 5A991B1 |
| HTSUS | 8542.39.0001 |
