MC33151DG Low-Side Gate Driver IC Inverting 8-SOIC 6.5V ~ 18V
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | MC33151DG |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Output Isolation: | Non-Isolated | Internal Switch(s): | Yes |
|---|---|---|---|
| Voltage - Breakdown: | 700V | Topology: | Buck, Buck-Boost, Flyback |
| Duty Cycle: | 69% | Frequency - Switching: | 66kHz |
| Fault Protection: | Current Limiting, Open Loop, Over Temperature, Short Circuit | Operating Temperature: | -40°C ~ 150°C (TJ) |
Product Description
MC33151DG Low-Side Gate Driver IC Inverting 8-SOIC 6.5V ~ 18V
Specifications of MC33151DG
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Gate Drivers | |
| Mfr | onsemi |
| Series | - |
| Package | Tube |
| Driven Configuration | Low-Side |
| Channel Type | Independent |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 6.5V ~ 18V |
| Logic Voltage - VIL, VIH | 0.8V, 2.6V |
| Current - Peak Output (Source, Sink) | 1.5A, 1.5A |
| Input Type | Inverting |
| Rise / Fall Time (Typ) | 31ns, 32ns |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | MC33151 |
Features of MC33151DG
• Two Independent Channels with 1.5 A Totem Pole Output
• Output Rise and Fall Times of 15 ns with 1000 pF Load
• CMOS/LSTTL Compatible Inputs with Hysteresis
• Undervoltage Lockout with Hysteresis
• Low Standby Current
• Efficient High Frequency Operation
• Enhanced System Performance with Common Switching Regulator Control ICs
• Pin Out Equivalent to DS0026 and MMH0026
• These are Pb−Free and Halide−Free Devices
Descriptions of MC33151DG
The MC34151/MC33151 are dual inverting high speed drivers specifically designed for applications that require low current digital circuitry to drive large capacitive loads with high slew rates.
Environmental & Export Classifications of MC33151DG
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
