AD580JH Electronic Components Series Voltage Reference IC Fixed 2.5V V ±3% 10 mA TO-52-3
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | STPS30L30CG |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Reference Type: | Series | Output Type: | Fixed |
|---|---|---|---|
| Voltage - Output (Min/Fixed): | 2.5 V | Voltage - Out1put (Min/Fixed): | 10mA |
| Tolerance: | ±3% | Temperature Coefficient: | 85ppm/°C |
| Noise - 0.1Hz To 10Hz: | 8µVp-p | Voltage - Input: | 4.5V ~ 30V |
| High Light: | AD580JH,AD580JH Electronic Components,Voltage Reference IC |
||
Product Description
AD580JH Electronic Components Series Voltage Reference IC Fixed 2.5V V ±3% 10 mA TO-52-3
Specifications of AD580JH
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Reference | |
| Mfr | Analog Devices Inc. |
| Series | - |
| Package | Bulk |
| Reference Type | Series |
| Output Type | Fixed |
| Voltage - Output (Min/Fixed) | 2.5V |
| Current - Output | 10 mA |
| Tolerance | ±3% |
| Temperature Coefficient | 85ppm/°C |
| Noise - 0.1Hz to 10Hz | 8µVp-p |
| Noise - 10Hz to 10kHz | - |
| Voltage - Input | 4.5V ~ 30V |
| Current - Supply | 1.5mA |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | TO-206AC, TO-52-3 Metal Can |
| Supplier Device Package | TO-52-3 |
| Base Product Number | AD580 |
Features of AD580JH
* Laser-trimmed to high accuracy: 2.500 V ±0.4%
* 3-terminal device: voltage in/voltage out
* Excellent temperature stability: 10 ppm/°C (AD580M, U)
* Excellent long-term stability: 250 μV (25 μV/month)
* Low quiescent current: 1.5 mA maximum
* Small, hermetic IC package: TO-52 can
* MIL-STD-883 compliant versions available
Applications of AD580JH
The AD580 is a 3-terminal, low cost, temperature-compensated, bandgap voltage reference, which provides a fixed 2.5 V output for inputs between 4.5 V and 30 V.
Environmental & Export Classifications of AD580JH
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
