CD4094BF Shift Electronic IC ChipsRegister 1 Element 8 Bit 16-CDIP
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | CD4094BF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Logic Type: | Shift Register | Output Type: | Tri-State |
|---|---|---|---|
| Number Of Elements: | 1 | Number Of Bits Per Element: | 8 |
| Function: | Serial To Parallel | Voltage - Supply: | 3V ~ 18V |
| Operating Temperature: | -55°C ~ 125°C (TA) | Mounting Type: | Through Hole |
Product Description
CD4094BF Shift Electronic IC ChipsRegister 1 Element 8 Bit 16-CDIP
Specifications of CD4094BF
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Shift Registers | |
| Mfr | Texas Instruments |
| Series | 4000B |
| Package | Tube |
| Logic Type | Shift Register |
| Output Type | Tri-State |
| Number of Elements | 1 |
| Number of Bits per Element | 8 |
| Function | Serial to Parallel |
| Voltage - Supply | 3V ~ 18V |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 16-CDIP |
Features of CD4094BF
* 3-state parallel outputs for connection to common bus
* Separate serial outputs synchronous to both positiveand negative clock edgas for cascading
* Medium speed operation -- 5 MHz at 10 V (typ.)
* Standardized, symmetrical output characteristics
* 100% tested for quiescent current at 20 V
* Maximum input current of 1 pA at 18 V over full packagetemperature range; 100 nA at 18 V and 25°C
* Noise margin (full package temperature range):ivat Vogs5at Vo -152Vat VDD= 10 Vm
* 5V, 10-V, and 15-V parametric ratings
* Meets all requirements of JEDEC TentativeStandard No,138,"Standard Specificationsfor Description of"B” Series CMOS Devices"
Applications of CD4094BF
The"107 contain two independent J-K flip-flops withindividuat J-K, clock, and direct clear inputs.
Environmental & Export Classifications of CD4094BF
| ATTRIBUTE | DESCRIPTION |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
