MLX92212LSE-ABA-000-RE Digital Switch IC Unipolar Switch Open Drain Hall Effect
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SS15-E3/61T |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Function: | Unipolar Switch | Sensing Range: | 15.4mT Trip, 7.8mT Release |
|---|---|---|---|
| Current - Supply (Max): | 3.2mA | Current - Output (Max): | 20mA |
| Output Type: | Open Drain | Operating Temperature: | -40°C ~ 150°C (TA) |
| Mounting Type: | Surface Mount | Package / Case: | TO-236-3, SC-59, SOT-23-3 |
| High Light: | MLX92212LSE-ABA-000-RE,MLX92212LSE-ABA-000-RE Digital Switch IC,Unipolar Digital Switch IC |
||
Product Description
MLX92212LSE-ABA-000-RE Digital Switch Unipolar Switch Open Drain Hall Effect
Specifications of SS15-E3/61T
| TYPE | DESCRIPTION |
| Switches (Solid State) | |
| Mfr | Melexis Technologies NV |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Function | Unipolar Switch |
| Sensing Range | 15.4mT Trip, 7.8mT Release |
| Current - Supply (Max) | 3.2mA |
| Current - Output (Max) | 20mA |
| Output Type | Open Drain |
| Features | - |
| Operating Temperature | -40°C ~ 150°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | TSOT-23-3 |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Base Product Number | MLX92212 |
Features of SS15-E3/61T
* Low voltage supply : from 2.5V to 5.5V
* Chopper-stabilized amplifier stage
* Low power switch: 2.1mA
* Wide temperature range: -40C to 150C
* Automotive qualified: AEC-Q100
* Optimized ESD performance: 8kV
* Designed for standalone PCB applications
* Thin SOT23 3L Green Compliant package
Applications of SS15-E3/61T
* Automotive, Consumer and Industrial
* BLDC motor commutation
* Solid-state Latch
* Low power applications
* Index counting
* Electrical power steering
Environmental & Export Classifications of SS15-E3/61T
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
