LTST-G683GEBW Blue LED Indication Discrete 2.1V Red, 3.3V Electronic Components
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | LTST-G683GEBW |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 3-5ddays |
| Payment Terms: | T/T |
| Supply Ability: | 1000 |
|
Detail Information |
|||
| Configuration: | Independent | Lens Transparency: | Diffused |
|---|---|---|---|
| Millicandela Rating: | 627.5mcd Red, 1570mcd Green, 267.5mcd Blue | Lens Style: | Square With Flat Top |
| Voltage - Forward (Vf) (Typ): | 2.1V Red, 3.3V Green, 3.3V Blue | Current - Test: | 20mA Red, 20mA Green, 20mA Blue |
| Viewing Angle: | 120° | Size / Dimension: | 3.30mm L X 3.00mm W |
Product Description
LTST-G683GEBW Blue LED Indication Discrete 2.1V Red, 3.3V Electronic Components
Specifications of LTST-G683GEBW
| TYPE | DESCRIPTION |
| Category | Optoelectronics |
| LED Indication - Discrete | |
| Mfr | Lite-On Inc. |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Product Status | Active |
| Color | Red, Green, Blue (RGB) |
| Configuration | Independent |
| Lens Color | - |
| Lens Transparency | Diffused |
| Millicandela Rating | 627.5mcd Red, 1570mcd Green, 267.5mcd Blue |
| Lens Style | Square with Flat Top |
| Lens Size | - |
| Voltage - Forward (Vf) (Typ) | 2.1V Red, 3.3V Green, 3.3V Blue |
| Current - Test | 20mA Red, 20mA Green, 20mA Blue |
| Viewing Angle | 120° |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | 623nm Red, 525nm Green, 470nm Blue |
| Wavelength - Peak | 630nm Red, 518nm Green, 465nm Blue |
| Features | - |
| Package / Case | 6-SMD, J-Lead |
| Supplier Device Package | 6-PLCC |
| Size / Dimension | 3.30mm L x 3.00mm W |
| Height (Max) | 1.45mm |
| Base Product Number | LTST-G683 |
Features of LTST-G683GEBW
* Meet ROHS
* Package in 8mm tape on 7" diameter reels
* EIA STD package
* I.C. compatible
* Compatible with automatic placement equipment
* Compatible with infrared reflow solder process
* Preconditioning: accelerate to JEDEC level 3
Applications of LTST-G683GEBW
* Telecommunication, Office automation, home appliances, industrial equipment
* Status indicator
* Signal and Symbol Luminary
* Front panel backlighting
Environmental & Export Classifications of LTST-G683GEBW
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.41.0000 |
