DF12(5.0)-20DP-0.5V(86) 20 Position Connector Header, Outer Shroud Contacts
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SML-LXT0805GW-TR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 3-5ddays |
| Payment Terms: | T/T |
| Supply Ability: | 1000 |
|
Detail Information |
|||
| Features: | Board Guide, Solder Retention | Series: | DF12 |
|---|---|---|---|
| Package: | Tape & Reel (TR) | Product Status: | Obsolete |
| Connector Type: | Header, Outer Shroud Contacts | Number Of Positions: | 20 |
| Pitch: | 0.020" (0.50mm) | Number Of Rows: | 2 |
| Contact Finish Thickness: | 8.00µin (0.203µm) | Mated Stacking Heights: | 5mm |
| High Light: | Outer Shroud Contacts Connector Header,20 Position Connector Header |
||
Product Description
DF12(5.0)-20DP-0.5V(86) 20 Position Connector Header, Outer Shroud Contacts
CONN HDR 20POS SMD GOLD
Specifications of DF12(5.0)-20DP-0.5V(86)
| TYPE | DESCRIPTION |
| Category | Arrays, Edge Type, Mezzanine (Board to Board) |
| Mfr | Hirose Electric Co Ltd |
| Series | DF12 |
| Package | Tape & Reel (TR) |
| Product Status | Obsolete |
| Connector Type | Header, Outer Shroud Contacts |
| Number of Positions | 20 |
| Pitch | 0.020" (0.50mm) |
| Number of Rows | 2 |
| Mounting Type | Surface Mount |
| Features | Board Guide, Solder Retention |
| Contact Finish | Gold |
| Contact Finish Thickness | 8.00µin (0.203µm) |
| Mated Stacking Heights | 5mm |
| Height Above Board | 0.169" (4.30mm) |
Features of DF12(5.0)-20DP-0.5V(86)
* Wide Variety of Stacking Heights
* Pick & Place Mounting
* Solder Tabs on the Soldering Portion
* 5Gbps Transmission Speed
Introduction of DF12(5.0)-20DP-0.5V(86)
* Refer to the chart below when determining the product specifications from the product number.
* Please select from the product numbers listed in this catalog when placing orders.
Environmental & Export Classifications of DF12(5.0)-20DP-0.5V(86)
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | RoHS Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| ECCN | EAR99 |
| HTSUS | 8536.69.4040 |
