38KHZ 45M Remote Receiver Sensor REC TSOP39338 Through Hole Mount
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | TSOP39338 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Package Product Status: | Bulk | Product Status: | Active |
|---|---|---|---|
| Sensing Distance: | 45m | B.P.F. Center Frequency: | 38.0kHz |
| Voltage - Supply: | 2.5 V ~ 5.5 V | Current - Supply: | 450 µA |
| Orientation: | Top View | Mounting Type: | Through Hole |
| High Light: | TSOP39338,45M Remote Receiver Sensor,38KHZ Remote Receiver Sensor |
||
Product Description
TSOP39338 Power Switch Ics Sensor Remote Rec 38.0khz 45m Tsop39338-Nd
Remote Receiver Sensor 38.0kHz 45m Through Hole
Specifications of TSOP39338
| TYPE | DESCRIPTION |
| Category | Sensors, Transducers |
| Optical Sensors | |
| Photo Detectors - Remote Receiver | |
| Mfr | Vishay Semiconductor Opto Division |
| Series | - |
| Package | Bulk |
| Product Status | Active |
| Sensing Distance | 45m |
| B.P.F. Center Frequency | 38.0kHz |
| Voltage - Supply | 2.5 V ~ 5.5 V |
| Current - Supply | 450 µA |
| Orientation | Top View |
| Mounting Type | Through Hole |
| Operating Temperature | -25°C ~ 85°C |
| Base Product Number | TSOP39338 |
Features of TSOP39338
• Very low supply current
• Photo detector and preamplifier in one package
• Internal filter for PCM frequency
• Supply voltage: 2.5 V to 5.5 V
• Improved immunity against ambient light
• Two lenses for high sensitivity
• Insensitive to supply voltage ripple and noise
• Ultra small top-view PCB footprint
• Material categorization: for definitions of compliance please see www.vishay.com/doc?99912
Applications of TSOP39338
The TSOP39... series are miniaturized receiver modules for infrared remote control systems. Two PIN diodes and a preamplifier are assembled on a leadframe, the epoxy package contains an IR filter. The demodulated output signal can be directly connected to digital circuitry for decoding.
Environmental & Export Classifications of TSOP39338
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 4 (72 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.49.9500 |
