INA240A2EDRQ1 WIRELESS RF MODULE IC CURRENT SENSE 1 CIRCUIT 8SOIC
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | INA240A2EDRQ1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Current - Supply: | 1.8mA | Voltage - Supply Span (Min): | 2.7 V |
|---|---|---|---|
| Voltage - Supply Span (Max): | 5.5 V | Operating Temperature: | -40°C ~ 150°C (TA) |
| Mounting Type: | Surface Mount | Package / Case: | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package: | 8-SOIC | Base Product Number: | INA240 |
Product Description
Ina240a2edrq1 Wireless Rf Module Ic Current Sense 1 Circuit 8soic
Current Sense Amplifier 1 Circuit 8-SOIC
Specifications of INA240A2EDRQ1
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Linear | |
| Amplifiers | |
| Instrumentation, OP Amps, Buffer Amps | |
| Mfr | Texas Instruments |
| Series | Automotive, AEC-Q100, Zero-Drift |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Amplifier Type | Current Sense |
| Number of Circuits | 1 |
| Output Type | - |
| Slew Rate | 2V/µs |
| -3db Bandwidth | 400 kHz |
| Current - Input Bias | 90 µA |
| Voltage - Input Offset | 5 µV |
| Current - Supply | 1.8mA |
| Voltage - Supply Span (Min) | 2.7 V |
| Voltage - Supply Span (Max) | 5.5 V |
| Operating Temperature | -40°C ~ 150°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | INA240 |
Features of INA240A2EDRQ1
• AEC-Q100 Qualified for Automotive Applications
– Temperature Grade 1: –40°C to +125°CAmbient Operating Temperature Range
– Temperature Grade 0: –40°C to +150°C
Ambient Operating Temperature Range
– HBM ESD Classification Level H2
– CDM ESD Classification Level C5
• Functional Safety-Capable
– Documentation available to aid functionalsafety system design
• Enhanced PWM Rejection
• Excellent CMRR:
– 132-dB DC CMRR
– 93-dB AC CMRR at 50 kHz
• Wide Common-Mode Range: –4 V to 80 V
• Accuracy:
– Gain Error: 0.20% (Maximum) With 2.5 ppm/°C(Maximum Drift)
– Offset Voltage: ±25 μV (Maximum) With 250nV/°C (Maximum Drift)
• Available Gains:
– INA240A1-Q1: 20 V/V
– INA240A2-Q1: 50 V/V
– INA240A3-Q1: 100 V/V
– INA240A4-Q1: 200 V/V
Applications of INA240A2EDRQ1
• Electronic Power Steering
• Stability and Traction Control
• Motor and Actuator Control
• Solenoid and Valve Control
Environmental & Export Classifications of INA240A2EDRQ1.
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.33.0001 |
