CY8C21334-24PVXAT Electronic IC Chips Dac Audio 24bit 200K 28TSSOP
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | CY8C21334-24PVXAT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Package: | Tape & Reel (TR) | Product Status: | Last Time Buy |
|---|---|---|---|
| Core Processor: | M8C | Core Size: | 8-Bit |
| Speed: | 24MHz | Connectivity: | I²C, SPI, UART/USART |
| Peripherals: | POR, PWM, WDT | Number Of I/O: | 16 |
| High Light: | CY8C21334-24PVXAT,Dac Audio 24bit 200K 28TSSOP,200K 28TSSOP IC Chip |
||
Product Description
CY8C21334-24PVXAT Wireless Rf Module Ic Chip Dac/Audio 24bit 200k 28tssop
M8C PSOC®1 CY8C21xxx Microcontroller IC 8-Bit 24MHz 8KB (8K x 8) FLASH 20-SSOP
Specifications of CY8C21334-24PVXAT
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Embedded | |
| Microcontrollers | |
| Mfr | Infineon Technologies |
| Series | PSOC®1 CY8C21xxx |
| Package | Tape & Reel (TR) |
| Product Status | Last Time Buy |
| Core Processor | M8C |
| Core Size | 8-Bit |
| Speed | 24MHz |
| Connectivity | I²C, SPI, UART/USART |
| Peripherals | POR, PWM, WDT |
| Number of I/O | 16 |
| Program Memory Size | 8KB (8K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 512 x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.4V ~ 5.25V |
| Data Converters | A/D 28x8b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 20-SSOP (0.209", 5.30mm Width) |
| Supplier Device Package | 20-SSOP |
| Base Product Number | CY8C21334 |
Features of CY8C21334-24PVXAT
■ Automotive Electronics Council (AEC) Q100 qualified
■ Powerful Harvard-architecture processor
❐ M8C processor speeds up to 24 MHz
❐ Low power at high speed
❐ Operating voltage: 3.0 V to 5.25 V
❐ Automotive temperature range: –40 C to +85 C
■ Advanced peripherals (PSoC® blocks)
❐ Four analog Type E PSoC blocks provide:
• Two comparators with digital-to-analog converter (DAC) references
• Up to 10-bit single or dual, 24 channel analog-to-digital converters (ADC)
❐ Four digital PSoC blocks provide:
• 8- to 32-bit timers, counters, and pulse width modulators (PWMs)
• Cyclical redundancy check (CRC) and pseudo-random sequence (PRS) modules
• Full- or half-duplex UART
• SPI master or slave
• Connectable to all general purpose I/O (GPIO) pins
❐ Complex peripherals by combining blocks
• Capacitive sensing application capability
■ Flexible on-chip memory
❐ 8 KB flash program storage
❐ 512 bytes SRAM data storage
❐ In-system serial programming (ISSP)
❐ Partial flash updates
❐ Flexible protection modes
❐ EEPROM emulation in flash
■ Complete development tools
❐ Free development software (PSoC Designer™)
❐ Full-featured in-circuit emulator (ICE) and programmer
❐ Full-speed emulation
❐ Complex breakpoint structure
❐ 128 KB trace memory
■ Precision, programmable clocking
❐ Internal ±5% 24 MHz oscillator
❐ Internal low-speed, low-power oscillator for Watchdog and Sleep functionality
❐ Optional external oscillator, up to 24 MHz
■ Programmable pin configurations
❐ 25 mA sink, 10 mA drive on all GPIOs
❐ Pull-up, pull-down, high Z, strong, or open drain drive modes on all GPIOs
❐ Analog input on all GPIOs
❐ Configurable interrupt on all GPIOs
■ Versatile analog mux
❐ Common internal analog bus
❐ Simultaneous connection of I/O combinations
■ Additional system resources
❐ Inter-Integrated Circuit (I2C™) master, slave, or multi-master operation up to 400 kHz
❐ Watchdog and sleep timers
❐ User-configurable low-voltage detection (LVD)
❐ Integrated supervisory circuit
❐ On-chip precision voltage reference
Applications of CY8C21334-24PVXAT
■ PWMs (8- to 32-bit)
■ PWMs with dead band (8- to 24-bit)
■ Counters (8- to 32-bit)
■ Timers (8- to 32-bit)
■ Full or half-duplex 8-bit UART with selectable parity
■ SPI master and slave
■ I 2C master, slave, or multi-master (implemented in a dedicated I 2C block)
■ Cyclical redundancy checker/generator (16-bit)
■ Infrared Data Association (IrDA)
■ PRS generators (8- to 32-bit)
Environmental & Export Classifications of CY8C21334-24PVXAT
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.31.0001 |
