AMC1200STDUBRQ1 Transistor Output Optocouplers 1 8-SOP 100 kHz 5.4mA
Product Details:
| Place of Origin: | Original |
| Brand Name: | Original |
| Certification: | Original |
| Model Number: | AMC1200STDUBRQ1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Part Number: | AMC1200STDUBRQ1 | Number Of Circuits: | 1 |
|---|---|---|---|
| -3db Bandwidth: | 100 KHz | Voltage - Input Offset: | 200 µV |
| Current - Supply: | 5.4mA | Current - Output / Channel: | 20 MA |
| Voltage - Supply Span (Min): | 2.7 V | Voltage - Supply Span (Max): | 5.5 V |
Product Description
AMC1200STDUBRQ1 Transistor Output Optocouplers 1 8-SOP 100 kHz 5.4mA
Isolation Amplifier 1 Circuit Differential 8-SOP
The AMC1200-Q1 is available in a wide-body, 8-pin SOIC package (DWV) and a gullwing, 8-pin SOP package (DUB).
Features of AMC1200STDUBRQ1
• Qualified for Automotive Applications
• AEC-Q100 Qualified With the Following Results:
– Temperature Grade 2: –40°C to 105°C
– HBM ESD Classification Level H2
– CDM ESD Classification Level C3B
• ±250-mV Input Voltage Range Optimized for
Shunt Resistors
• Very Low Nonlinearity: 0.075% (max)
with 5-V High-Side Supply
• Low Offset Error: 1.5 mV (max)
• Low Noise: 3.1 mVRMS (typical)
• Low High-Side Supply Current:
8 mA (max) at 5 V
• Input Bandwidth: 60 kHz (min)
• Fixed Gain: 8 (0.5% accuracy)
• High Common-Mode Rejection Ratio:
108 dB (typical)
• 3.3-V Operation on Low-Side
• Certified Galvanic Isolation:
– UL1577 and VDE V 0884-10 Approved
– Isolation Voltage: 4250 VPEAK
– Working Voltage: 1200 VPEAK
– Transient Immunity: 10 kV/µs (min)
Product Attributes of AMC1200STDUBRQ1
|
Series
|
Automotive, AEC-Q100
|
|
Product
|
AMC1200STDUBRQ1
|
|
Amplifier Type
|
Isolation
|
|
Number of Circuits
|
1
|
|
Output Type
|
Differential
|
|
Slew Rate
|
-
|
|
-3db Bandwidth
|
100 kHz
|
|
Voltage - Input Offset
|
200 µV
|
|
Current - Supply
|
5.4mA
|
|
Current - Output / Channel
|
20 mA
|
|
Voltage - Supply Span (Min)
|
2.7 V
|
|
Voltage - Supply Span (Max)
|
5.5 V
|
|
Operating Temperature
|
-40°C ~ 105°C
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
8-SMD, Gull Wing
|
|
Supplier Device Package
|
8-SOP
|
|
Base Product Number
|
AMC1200
|
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.33.0001 |
Applications of AMC1200STDUBRQ1
• Isolated Shunt-Resistor-Based Current or Voltage
Sensing in:
– Traction Inverters
– On-Board Chargers
– DC-DC Converters
– Battery Management Systems
