LMZ35003RKGR Non-Isolated PoL Module DC Converter 1 Output 2.5 ~ 15V
Product Details:
| Place of Origin: | Original |
| Brand Name: | Original |
| Certification: | Original |
| Model Number: | LMZ35003RKGR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Topology: | Buck | Voltage - Input (Min): | 2.7V |
|---|---|---|---|
| Voltage - Input (Max): | 5.5V | Voltage - Output 1: | 0.6 ~ 3.6V |
| Size / Dimension: | 0.12" L X 0.10" W X 0.06" H (3.0mm X 2.6mm X 1.5mm) | Supplier Device Package: | 8-uSIP |
Product Description
LMZ35003RKGR Non-Isolated PoL Module DC Converter 1 Output 2.5 ~ 15V
Non-Isolated PoL Module DC DC Converter 1 Output 2.5 ~ 15V 2.5A 7V - 50V Input
Applications of LMZ35003RKGR
• Industrial and Motor Controls
• Automated Test Equipment
• Medical and Imaging Equipment
• High Density Power Systems
|
TYPE
|
DESCRIPTION
|
|---|---|
|
Category
|
Power Supplies - Board Mount
DC DC Converters
|
|
Mfr
|
T Instruments
|
|
Series
|
SIMPLE SWITCHER®
|
|
Product Status
|
Active
|
|
Type
|
Non-Isolated PoL Module
|
|
Number of Outputs
|
1
|
|
Voltage - Input (Min)
|
7V
|
|
Voltage - Input (Max)
|
50V
|
|
Voltage - Output 1
|
2.5 ~ 15V
|
|
Voltage - Output 2
|
-
|
|
Voltage - Output 3
|
-
|
|
Current - Output (Max)
|
2.5A
|
|
Applications
|
ITE (Commercial)
|
|
Features
|
OCP, OTP, UVLO
|
|
Operating Temperature
|
-40°C ~ 85°C
|
|
Efficiency
|
93%
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
41-BQFN Module
|
|
Size / Dimension
|
0.44" L x 0.36" W x 0.11" H (11.2mm x 9.2mm x 2.9mm)
|
|
Supplier Device Package
|
41-B1QFN (11x9)
|
|
Control Features
|
Enable, Active High
|
|
Base Product Number
|
LMZ35003
|
Features of LMZ35003RKGR
• Complete Integrated Power Solution Allows Small Footprint, Low-Profile Design
• Wide Input Voltage Range from 7 V to 50 V
• Output Adjustable from 2.5 V to 15 V
• 65-V Surge Capability
• Efficiencies Up To 96%
• Adjustable Switching Frequency (300 kHz to 1 MHz)
• Synchronizes to an External Clock
• Adjustable Slow-Start
• Output Voltage Sequencing and Tracking
• Power Good Output
• Programmable Undervoltage Lockout (UVLO)
• Output Overcurrent Protection
• Over Temperature Protection
• Pre-bias Output Start-up
• Operating Temperature Range: –40°C to 85°C
• Enhanced Thermal Performance: 14°C/W
• Meets EN55022 Class B Emissions
- Integrated Shielded Inductor
• For Design Help visit http://www.ti.com/LMZ35003
• Create a Custom Design Using the LMZ35003 With the WEBENCH® Power Designer
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8504.40.9580 |
