NCP699SN15T1G Linear Voltage Regulator IC Positive Fixed 1 Output 150mA 5-TSOP
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | NCP699SN15T1G |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Output Type: | Fixed | Number Of Regulators: | 1 |
|---|---|---|---|
| Voltage - Input (Max): | 6V | Voltage - Output (Min/Fixed): | 1.5V |
| Voltage Dropout (Max): | 0.75V @ 150mA | Current - Output: | 150mA |
| Current - Quiescent (Iq): | 90 µA | PSRR: | 55dB ~ 50dB (120Hz ~ 1kHz) |
Product Description
NCP699SN15T1G Linear Voltage Regulator IC Positive Fixed 1 Output 150mA 5-TSOP
Specifications of NCP699SN15T1G
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Regulators - Linear | |
| Mfr | onsemi |
| Series | - |
| Package | Tape & Reel (TR) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 6V |
| Voltage - Output (Min/Fixed) | 1.5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.75V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 90 µA |
| PSRR | 55dB ~ 50dB (120Hz ~ 1kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-5 Thin, TSOT-23-5 |
| Supplier Device Package | 5-TSOP |
| Base Product Number | NCP699 |
Features of NCP699SN15T1G
• Enable Control (Active High, Supports Sub 1 V Logic)
• Very Low Ground Current of 40 A Typical
• Low Dropout Voltage of 340 mV at 150 mA, and 3.0 V Vout
• Multiple Fixed Output Voltage Option
• Output Voltage Accuracy of 2.0%
• Operating Temperature Range of −40°C to 85°C
• Stable with 1 F Ceramic or Tantalum Capacitors
• These are Pb−Free Devices
Descriptions of NCP699SN15T1G
Cellular Phones
• Battery Powered Consumer Products
• Hand−Held Instruments
• Camcorders and Cameras
• Printers and Office Equipment
Environmental & Export Classifications of NCP699SN15T1G
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
