TPS79633DCQR Linear Integrated Circuits Voltage Regulator 1 Output 1A SOT-223-6
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | TPS79633DCQR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Voltage - Input (Max): | 5.5V | Voltage - Output (Min/Fixed): | 3.3V |
|---|---|---|---|
| Voltage - Output (Max): | - | Voltage Dropout (Max): | 0.33V @ 1A |
| Current - Output: | 1A | Current - Quiescent (Iq): | 385µA |
| PSRR: | 59dB ~ 42dB (100Hz ~ 100kHz) | Control Features: | Enable |
| High Light: | TPS79633DCQR Linear Integrated Circuits,Voltage Regulator Linear Integrated Circuits,385µA Voltage Regulator IC |
||
Product Description
TPS79633DCQR Linear Integrated Circuits Voltage Regulator 1 Output 1A SOT-223-6
IC REG LINEAR 3.3V 1A SOT223-6
Specifications of TPS79633DCQR
| TYPE | DESCRIPTION |
| Category | Linear Voltage Regulators |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 3.3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.33V @ 1A |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 385 µA |
| PSRR | 59dB ~ 42dB (100Hz ~ 100kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | SOT-223-6 |
| Supplier Device Package | SOT-223-6 |
| Base Product Number | TPS79633 |
Features of TPS79633DCQR
*1-A Low-Dropout Regulator With Enable
*Available in Fixed and Adjustable (1.2 V to 5.5 V) Versions
*High PSRR (53 dB at 10 kHz)
*Ultralow-Noise (40 VRMs, TPS79630)
*Fast Start-Up Time (50 ps)
*Stable With a 1-pF Ceramic Capacitor
*Excellent Load and Line Transient Response
*Very Low Dropout Voltage (250 mV at Full Load,TPS79630)
*3 x 3 VSON PowerPADTM,SOT223-6, and TO-263 Packages
Applications of TPS79633DCQR
*RF: VCOs, Receivers, ADCs
*Audio
*Bluetooth, Wireless LAN
*Cellular and Cordless Telephones
*Handheld Organizers, PDAs
Environmental & Export Classifications of TPS79633DCQR
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
