STM8AF6286TAX Emmc Memory Chip Ic Mcu 8bit 64kb Flash 32lqfp
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | STM8AF6286TAX |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Series: | STM8A | Package: | Tape & Reel (TR) |
|---|---|---|---|
| Product Status: | Obsolete | Digi-Key Programmable: | Not Verified |
| Core Processor: | STM8A | Core Size: | 8-Bit |
| Connectivity: | 24MHz | Series STM8A Package Tape & Reel (TR) Product Status Obsolete Digi-Key Programmable Not Verified Cor: | I²C, LINbus, SPI, UART/USART |
Product Description
STM8AF6286TAX Emmc Memory Chip Ic Mcu 8bit 64kb Flash 32lqfp
STM8A STM8A Microcontroller IC 8-Bit 24MHz 64KB (64K x 8) FLASH 32-LQFP (7x7)
Specifications of STM8AF6286TAX
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Embedded | |
| Microcontrollers | |
| Mfr | STMicroelectronics |
| Series | STM8A |
| Package | Tape & Reel (TR) |
| Product Status | Obsolete |
| Digi-Key Programmable | Not Verified |
| Core Processor | STM8A |
| Core Size | 8-Bit |
| Speed | 24MHz |
| Connectivity | I²C, LINbus, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 25 |
| Program Memory Size | 64KB (64K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 2K x 8 |
| RAM Size | 6K x 8 |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Data Converters | A/D 7x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 32-LQFP |
| Supplier Device Package | 32-LQFP (7x7) |
| Base Product Number | STM8 |
Features of STM8AF6286TAX
• AEC-Q10x qualified
• Core
– Max fCPU: 24 MHz
– Advanced STM8A core with Harvard architecture and 3-stage pipeline
– Average 1.6 cycles/instruction resulting in 10 MIPS at 16 MHz fCPU for industry standard benchmark
• Memories
– Program memory: 32 to 128 Kbyte Flash program; data retention 20 years at 55 °C
– Data memory: up to 2 Kbyte true data EEPROM; endurance 300 kcycle
– RAM: 6 Kbyte
• Clock management
– Low-power crystal resonator oscillator with external clock input
– Internal, user-trimmable 16 MHz RC and low-power 128 kHz RC oscillators
– Clock security system with clock monitor
• Reset and supply management
– Wait/auto-wakeup/Halt low-power modes with user definable clock gating
– Low consumption power-on and powerdown reset
• Interrupt management
– Nested interrupt controller with 32 vectors
– Up to 37 external interrupts on 5 vectors
• Timers
– 2 general purpose 16-bit timers with up to 3 CAPCOM channels each (IC, OC, PWM)
– Advanced control timer: 16-bit, 4 CAPCOM channels, 3 complementary outputs, deadtime insertion and flexible synchronization
– 8-bit AR basic timer with 8-bit prescaler
– Auto-wakeup timer
– Window and independent watchdog timers
• I/Os
– Up to 68 user pins (11 high sink I/Os)
Applications of STM8AF6286TAX
• The memory is organized in blocks of 128 bytes each
• Read granularity: 1 word = 4 bytes
• Write/erase granularity: 1 word (4 bytes) or 1 block (128 bytes) in
• Writing, erasing, word and block management is handled automaticallyby the memory interface.
Environmental & Export Classifications of STM8AF6286TAX
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.31.0001 |
