MC68HC908JK3CDW Tantalum Chip Capacitor 2a 100v Schottky Auto
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | MC68HC908JK3CDW |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Mfr: | Onsemi | Series: | Automotive, AEC-Q101 |
|---|---|---|---|
| Package: | Tape & Reel (TR) | Product Status: | Active |
| Technology: | Schottky | Voltage - DC Reverse (Vr) (Max): | 100 V |
| Current - Average Rectified (Io): | 2A | Voltage - Forward (Vf) (Max) @ If: | 790 MV @ 2 A |
Product Description
MC68HC908JK3CDW Tantalum Chip Capacitor 2a 100v Schottky Auto
Diode 100 V 2A Surface Mount SMB
Specifications of MC68HC908JK3CDW
| TYPE | DESCRIPTION |
| Category | Discrete Semiconductor Products |
| Diodes | |
| Rectifiers | |
| Single Diodes | |
| Mfr | onsemi |
| Series | Automotive, AEC-Q101 |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Current - Average Rectified (Io) | 2A |
| Voltage - Forward (Vf) (Max) @ If | 790 mV @ 2 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Current - Reverse Leakage @ Vr | 8 µA @ 100 V |
| Capacitance @ Vr, F | - |
| Mounting Type | Surface Mount |
| Package / Case | DO-214AA, SMB |
| Supplier Device Package | SMB |
| Operating Temperature - Junction | -65°C ~ 175°C |
| Base Product Number | NBRS2H |
FEATURES of MC68HC908JK3CDW
• Compact Package with J−Bend Leads Ideal for Automated Handling
• Highly Stable Oxide Passivated Junction
• Guard−Ring for Overvoltage Protection
• Low Forward Voltage Drop
• NBR and NRVB Prefixes for Automotive and Other Applications Requiring Unique Site and Control Change Req
Applications of MC68HC908JK3CDW
• Case: Molded Epoxy
• Epoxy Meets UL 94 V−0 @ 0.125 in
• Weight: 70 mg (SMA), 95 mg (SMB) (Approximately)
• Cathode Polarity Band
• Lead and Mounting Surface Temperature for Soldering Purposes: 260°C Max. for 10 Seconds
• Finish: All External Surfaces Corrosion Resistant and Terminal Leads are Readily Solderable
• ESD Ratings:
♦ Charged Device Model > 1000 V (Class C5)
♦ Human Body Model = 3B
• These Devices are Pb−Free and are RoHS Compliant
• Device Meets MSL1 Requirements
Environmental & Export Classifications of MC68HC908JK3CDW
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.10.0080 |
