LMZM23600V5SILT Tvs Diode Smd Dc Converter 5v 296-49459-2-ND
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | LMZM23600V5SILT |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Features: | OCP, SCP, UVLO | Operating Temperature: | -40°C ~ 125°C |
|---|---|---|---|
| Efficiency: | 90% | Mounting Type: | Surface Mount |
| Package / Case: | 10-LDFN Exposed Pad, Module | Size / Dimension: | 0.15" L X 0.12" W X 0.06" H (3.8mm X 3.0mm X 1.6mm) |
| Supplier Device Package: | 10-uSIP (3.8x3) | Base Product Number: | LMZM23600 |
Product Description
LMZM23600V5SILT Tvs Diode Smd Dc Dc Converter 5v 296-49459-2-ND
Non-Isolated PoL Module DC DC Converter 1 Output 5V 500mA 4V - 36V Input
Specifications of LMZM23600V5SILT
| TYPE | DESCRIPTION |
| Category | Power Supplies - Board Mount |
| DC DC Converters | |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4V |
| Voltage - Input (Max) | 36V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 500mA |
| Applications | ITE (Commercial) |
| Features | OCP, SCP, UVLO |
| Operating Temperature | -40°C ~ 125°C |
| Efficiency | 90% |
| Mounting Type | Surface Mount |
| Package / Case | 10-LDFN Exposed Pad, Module |
| Size / Dimension | 0.15" L x 0.12" W x 0.06" H (3.8mm x 3.0mm x 1.6mm) |
| Supplier Device Package | 10-uSIP (3.8x3) |
| Base Product Number | LMZM23600 |
FEATURES of LMZM23600V5SILT
• 4-V to 36-V wide operating input voltage
• 1.2-V to 15-V adjustable, and 3.3-V or 5-V fixed output voltage options
• 0.5-A Output current
• Only input and output capacitors needed for 5-V and 3.3-V output designs
• 27-mm2 Solution size with single-sided layout
• 28-µA supply current at no load
• 2-µA shutdown current
• Power-good flag
• External frequency synchronization
Applications of LMZM23600V5SILT
• Sensor transmitters
• Test and measurement
• Grid infrastructure
• Space constrained applications
Environmental & Export Classifications of LMZM23600V5SILT
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8504.40.9580 |
