PDS1045-13 Tantalum Chip Capacitor 45V 10A POWERDI5 -65°C ~ 150°C
Product Details:
| Place of Origin: | Original |
| Brand Name: | Original |
| Certification: | Original |
| Model Number: | PDS1045-13 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Part Number: | PDS1045-13 | Voltage - DC Reverse (Vr) (Max): | 45 V |
|---|---|---|---|
| Current - Average Rectified (Io): | 10A | Voltage - Forward (Vf) (Max) @ If: | 510 MV @ 10 A |
| CCurrent - Reverse Leakage @ Vr: | 600 µA @ 45 V | Package / Case: | PowerDI™ 5 |
Product Description
PDS1045-13 Tantalum Chip Capacitor 45V 10A POWERDI5 -65°C ~ 150°C
Diode 45 V 10A Surface Mount PowerDI™ 5
Features of PDS1045-13
Guard Ring Die Construction for Transient Protection
Very Low Forward Voltage Drop
High Forward Surge Current Capability
For use in low voltage, high frequency inverters, freewheeling,
and polarity protection applications
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Case: POWERDI®5
Case Material: Molded Plastic, “Green” Molding Compound;
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin Annealed Over Copper Leadframe;
Solderable per MIL-STD-202, Method 208
Polarity: See Diagram
Weight: 0.096 grams (Approximate)
Specifications of PDS1045-13
|
Product
|
MMBD4448 -TP
|
|
Technology
|
Standard
|
|
Voltage - DC Reverse (Vr) (Max)
|
75 V
|
|
Current - Average Rectified (Io)
|
250mA
|
|
Voltage - Forward (Vf) (Max) @ If
|
1.25 V @ 150 mA
|
|
Speed
|
Fast Recovery =< 500ns, > 200mA (Io)
|
|
Reverse Recovery Time (trr)
|
4 ns
|
|
Current - Reverse Leakage @ Vr
|
2.5 µA @ 75 V
|
|
Capacitance @ Vr, F
|
4pF @ 0V, 1MHz
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
TO-236-3, SC-59, SOT-23-3
|
|
Supplier Device Package
|
SOT-23
|
|
Operating Temperature - Junction
|
-55°C ~ 150°C
|
|
Base Product Number
|
MMBD4448
|
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.10.0070 |
