MBR0540-TP Diode 40 V 500mA Surface Mount SOD-123 Tantalum Chip Capacitor
Product Details:
| Place of Origin: | Original |
| Brand Name: | Original |
| Certification: | Original |
| Model Number: | MBR0540-TP |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Part Number: | MBR0540-TP | Voltage - DC Reverse (Vr) (Max): | 40 V |
|---|---|---|---|
| Current - Average Rectified (Io): | 500mA | Current - Reverse Leakage @ Vr: | 200 µA @ 40 V |
| Capacitance @ Vr, F: | 30pF @ 4V, 1MHz | Package / Case: | SOD-123 |
Product Description
MBR0540-TP Diode 40 V 500mA Surface Mount SOD-123 Tantalum Chip Capacitor
Diode 40 V 500mA Surface Mount SOD-123
Features of MBR0540-TP
• Lead Free Finish/RoHS Compliant ("P" Suffix Designates RoHS
Compliant. See Ordering Information)
• For Surface Mount Application
• Low Forward Voltage And Extremely Low Thermal Resistance
• Halogen Free. “Green” Device (Note 1)
• Epoxy Meets UL 94 V-0 Flammability Rating
• Moisture Sensitivity Level 1
• Operating Junction Temperature Range: -55°C to +125°C
• Storage Temperature Range: -55°C to +150°C
• Maximum Thermal Resistance(Note 2): 244°C/W Junction to Ambient
Specifications of MBR0540-TP
|
Product
|
MBR0540-TP
|
|
Technology
|
Schottky
|
|
Voltage - DC Reverse (Vr) (Max)
|
40 V
|
|
Current - Average Rectified (Io)
|
500mA
|
|
Voltage - Forward (Vf) (Max) @ If
|
550 mV @ 500 mA
|
|
Speed
|
Fast Recovery =< 500ns, > 200mA (Io)
|
|
Current - Reverse Leakage @ Vr
|
200 µA @ 40 V
|
|
Capacitance @ Vr, F
|
30pF @ 4V, 1MHz
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
SOD-123
|
|
Supplier Device Package
|
SOD-123
|
|
Operating Temperature - Junction
|
-55°C ~ 150°C
|
|
Base Product Number
|
MBR0540
|
Applications of MBR0540-TP
0.5 Amp Schottky Rectifier 20 to 80 Volts
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.10.0070 |
