LMR62421XMFX/NOPB Switching Regulator IC REG BST SEPIC ADJ 2.1A SOT23
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | LMR62421XMFX/NOPB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Number Of Outputs: | 1 | Voltage - Input (Min): | 2.7V |
|---|---|---|---|
| Voltage - Input (Max): | 5.5V | Voltage - Output (Min/Fixed): | 2.7V |
| Voltage - Output (Max): | 24V | Current - Output: | 2.1A (Switch) |
| Frequency - Switching: | 1.6MHz | ||
| High Light: | SEPIC Power Management ICs,SOT23 Power Management ICs,LMR62421XMFX/NOPB |
||
Product Description
LMR62421XMFX/NOPB Switching Regulator IC REG BST SEPIC ADJ 2.1A SOT23
Boost, SEPIC Switching Regulator IC Positive Adjustable 2.7V 1 Output 2.1A (Switch) SC-74A, SOT-753
Specifications of LMR62421XMFX/NOPB
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Regulators - DC DC Switching Regulators | |
| Mfr | Texas Instruments |
| Series | SIMPLE SWITCHER® |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| Function | Step-Up, Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Boost, SEPIC |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 2.7V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 2.7V |
| Voltage - Output (Max) | 24V |
| Current - Output | 2.1A (Switch) |
| Frequency - Switching | 1.6MHz |
| Synchronous Rectifier | No |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SC-74A, SOT-753 |
| Supplier Device Package | SOT-23-5 |
| Base Product Number | LMR62421 |
Features of LMR62421XMFX/NOPB
*Input Voltage Range of 2.7V to 5.5V
*Output Voltage up to 24V
*Switch Current up to 2.1A
*1.6 MHz Switching Frequency
*Low Shutdown lq, 80 nACycle-by-Cycle Current Limiting
*Internally Compensated
*lnternal Soft-Start
*5-Pin SOT-23 (2.92 x 2.84 x 1mm) and 6-PinWSON (3 x 3 x 0.8 mm) Packaging
*Fully Enabled for WEBENCHO Power Designer
• Wide operating voltage range: 1.5 V – 5.5 V
• Reverse voltage standoff on VIN:
–6-V absolute maximum
• Maximum continuous current (IMAX): 1.5 A
• On-Resistance (RON):
– 5-V VIN = 79-mΩ (typical)
– 3.6-V VIN = 91-mΩ (typical)
– 1.8-V VIN = 141-mΩ (typical)
• Comparator chip enable (CE)
• Channel status indication (ST)
• Low current consumption:
– 3.6-V VIN Shutdown current (ISD,VIN): 120-nA (typical)
– 3.6-V VIN Quiescent current (IQ, VIN): 150-nA (typical)
Applications of LMR62421XMFX/NOPB
*Boost / SEPIC Conversions from 3.3V, 5V Rails
*Space Constrained Applications
*Embedded Systems
*LcD Displays
*LED Applications
Environmental & Export Classifications of LMR62421XMFX/NOPB
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
