GBU806 General Purpose Relays Bridge Rect 1phase 600v 8a Gbu
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | GBU806 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Package: | Tube | Product Status: | Active |
|---|---|---|---|
| Diode Type: | Single Phase | Technology: | Standard |
| Voltage - Peak Reverse (Max): | 600 V | Current - Average Rectified (Io): | 8 A |
| Voltage - Forward (Vf) (Max) @ If: | 1.1 V @ 8 A | Current - Reverse Leakage @ Vr: | 5 µA @ 600 V |
Product Description
GBU806 General Purpose Relays Bridge Rect 1phase 600v 8a Gbu
Bridge Rectifier Single Phase Standard 600 V Through Hole GBU
Specifications of GBU806
| TYPE | DESCRIPTION |
| Category | Discrete Semiconductor Products |
| Diodes | |
| Bridge Rectifiers | |
| Mfr | SMC Diode Solutions |
| Series | - |
| Package | Tube |
| Product Status | Active |
| Diode Type | Single Phase |
| Technology | Standard |
| Voltage - Peak Reverse (Max) | 600 V |
| Current - Average Rectified (Io) | 8 A |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 8 A |
| Current - Reverse Leakage @ Vr | 5 µA @ 600 V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | 4-ESIP |
| Supplier Device Package | GBU |
| Base Product Number | GBU806 |
Features of GBU806
• Glass passivated die construction
• Low forward voltage drop
• High current capability
• High surge current capability
• Plastic material-UL flammability 94V-0
• This is a Pb • Free Device
• All SMC parts are traceable to the wafer lot
• Additional testing can be offered upon request
Mechanical Data of GBU806
• Case: GBU, Molded plastic
• Terminals: Plated leads solderable per MIL-STD-202, Method 208
• Polarity: as marked on case
• Mounting Position: Any
• Lead Free: For RoHS / Lead Free Version
Environmental & Export Classifications of GBU806
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Affected |
| ECCN | EAR99 |
| HTSUS | 8541.10.0080 |
