EFR32MG12P132F1024GM48-CR General Purpose Relays Ic Rf Txrx+Mcu 802.15.4 48vfqfn
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | EFR32MG12P132F1024GM48-CR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Product Status: | Active | Power - Output: | 10dBm |
|---|---|---|---|
| Memory Size: | 1MB Flash, 128kB RAM | Serial Interfaces: | I²C, I²S, SPI, UART |
| GPIO: | 31RT | Voltage - Supply: | 1.8V ~ 3.8V |
| Operating Temperature: | -40°C ~ 85°C | Mounting Type: | Surface Mount |
Product Description
EFR32MG12P132F1024GM48-CR General Purpose Relays Ic Rf Txrx+Mcu 802.15.4 48vfqfn
IC RF TxRx + MCU 802.15.4, Bluetooth Bluetooth v5.0, Thread, Zigbee® 2.4GHz 48-VFQFN Exposed Pad
Specifications of EFR32MG12P132F1024GM48-CR
| TYPE | DESCRIPTION |
| Category | RF and Wireless |
| RF Transceiver ICs | |
| Mfr | Silicon Labs |
| Series | Mighty Gecko |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Digi-Key Programmable | Not Verified |
| Type | TxRx + MCU |
| RF Family/Standard | 802.15.4, Bluetooth |
| Protocol | Bluetooth v5.0, Thread, Zigbee® |
| Modulation | 2FSK, 2GFSK, 4FSK, 4GFSK, ASK, BPSK, DBPSK, DSSS, GFSK, GMSK, MSK, OOK, OQPSK |
| Frequency | 2.4GHz |
| Data Rate (Max) | - |
| Power - Output | 10dBm |
| Memory Size | 1MB Flash, 128kB RAM |
| Serial Interfaces | I²C, I²S, SPI, UART |
| GPIO | 31 |
| Voltage - Supply | 1.8V ~ 3.8V |
| Current - Receiving | - |
| Current - Transmitting | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 48-VFQFN Exposed Pad |
| Supplier Device Package | 48-QFN (7x7) |
| Base Product Number | EFR32MG12P132 |
Features of EFR32MG12P132F1024GM48-CR
• 32-bit ARM® Cortex®-M4 core with 40 MHz maximum operating frequency
• Up to 1 MB of flash and 256 kB of RAM
• Pin-compatible across EFR32MG families (exceptions apply for 5V-tolerant pins)
• 12-channel Peripheral Reflex System, Low-Energy Sensor Interface & Multichannel Capacitive Sense Interface
• Autonomous Hardware Crypto Accelerator and True Random Number Generator
• Integrated PA with up to 19 dBm (2.4 GHz) or 20 dBm (Sub-GHz) TX power
• Integrated balun for 2.4 GHz
• Robust peripheral set and up to 65 GPIO
Applications of EFR32MG12P132F1024GM48-CR
• IoT Multi-Protocol Devices
• Connected Home
• Lighting
• Health and Wellness
• Metering
• Home and Building Automation and Security
Environmental & Export Classifications of EFR32MG12P132F1024GM48-CR
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | RoHS Compliant |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| ECCN | 5A992C |
| HTSUS | 8542.39.0001 |
