PTN78000WAZ Integrated Circuit Chip Converter 1 2.5 ~ 12.6V 1.5A 7V - 36V
Product Details:
| Place of Origin: | Original |
| Brand Name: | Original |
| Certification: | Original |
| Model Number: | PTN78000WAZ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Part No: | PTN78000WAZ | Number Of Outputs: | 1 |
|---|---|---|---|
| Voltage - Input (Min): | 7V | Voltage - Input (Max): | 36V |
| Voltage - Output: | 1 2.5 ~ 12.6V | Current - Output (Max): | 1.5A |
| Operating Temperature: | -40°C ~ 85°C | Efficiency: | 91% |
Product Description
PTN78000WAZ Integrated Circuit Chip Converter 1 2.5 ~ 12.6V 1.5A 7V - 36V
Non-Isolated PoL Module DC DC Converter 1 Output 2.5 ~ 12.6V 1.5A 7V - 36V Input
Features of PTN78000WAZ
1.5-A Output Current · Wide-Input Voltage
(7V to 36 V)/(15V to 36 V)
Wide-Output Voltage Adjust (2.5V to 12.6 V)/(11.85V to 22V)
High Efficiency (Up to 95%)
On/Off Inhibit
Undervoltage Lockout
Output Current Limit
Overtemperature Shutdown
Operating Temperature:-40°C to 85°C
Surface Mount Package Available
Specifications of PTN78000WAZ
|
Mfr
|
Texas Instruments
|
|
Series
|
PTN78000W
|
|
Product
|
PTN78000WAZ
|
|
Type
|
Non-Isolated PoL Module
|
|
Number of Outputs
|
1
|
|
Voltage - Input (Min)
|
7V
|
|
Voltage - Input (Max)
|
36V
|
|
Voltage - Output 1
|
2.5 ~ 12.6V
|
|
Voltage - Output 2
|
-
|
|
Voltage - Output 3
|
-
|
|
Current - Output (Max)
|
1.5A
|
|
Applications
|
ITE (Commercial)
|
|
Features
|
OCP, OTP, UVLO
|
|
Operating Temperature
|
-40°C ~ 85°C
|
|
Efficiency
|
91%
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
5-SMD Module
|
|
Size / Dimension
|
0.75" L x 0.50" W x 0.36" H (19.1mm x 12.7mm x 9.1mm)
|
|
Base Product Number
|
PTN78000
|
range (−10 ̊
Environmental & Export Classifications
wh avck-
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Affected |
| ECCN | EAR99 |
| HTSUS | 8504.40.9580 |
APPLICATIONS of PTN78000WAZ
General-Purpose,Industrial Controls,
HVAC Systems,Test and Measurement, Medical Instrumentation,AC/DC Adaptors Vehicles, Marine, and Avionics
