AMC1306M25DWVR Isolated Module 16 b 78k CMOS, Serial 8-SOIC
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | AMC1306M25DWVR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Number Of Channels: | 1 | Resolution (Bits): | 16 B |
|---|---|---|---|
| Sampling Rate (Per Second): | 78k | Data Interface: | CMOS, Serial |
| Voltage Supply Source: | Analog And Digital | Voltage - Supply: | 2.7V ~ 5.5V |
| Operating Temperature: | -40°C ~ 125°C | Mounting Type: | Surface Mount |
Product Description
ADS1605IPAPR 16 Bit Analog to Digital Converter 1 Input 1 Sigma-Delta 64-HTQFP
Specifications of AMC1306M25DWVR
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Data Acquisition | |
| ADCs/DACs - Special Purpose | |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Type | Isolated Module |
| Number of Channels | 1 |
| Resolution (Bits) | 16 b |
| Sampling Rate (Per Second) | 78k |
| Data Interface | CMOS, Serial |
| Voltage Supply Source | Analog and Digital |
| Voltage - Supply | 2.7V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | AMC1306 |
Features of AMC1306M25DWVR
• Pin-compatible family optimized for shunt-resistorbased current measurements:
– ±50-mV or ±250-mV input voltage ranges
– Manchester coded or uncoded bitstream options
• Excellent DC performance:
– Offset error: ±50 µV or ±100 µV (max)
– Offset drift: 1 µV/°C (max)
– Gain error: ±0.2% (max)
– Gain drift: ±40 ppm/°C (max)
• Transient immunity: 100 kV/µs (typ)
• System-level diagnostic features
• Safety-related certifications:
– 7000-VPEAK reinforced isolation per DIN VDE V 0884-11: 2017-01
– 5000-VRMS isolation for 1 minute per UL1577
– CAN/CSA no. 5A-component acceptance service notice and IEC 62368-1 end equipment standard
• Fully specified over the extended industrial temperature range: –40°C to +125°C
Applications of AMC1306M25DWVR
• Shunt-resistor-based current sensing and isolated voltage measurements in:
– Industrial motor drives
– Photovoltaic inverters
– Uninterruptible power supplies
Environmental & Export Classifications of AMC1306M25DWVR
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
