LM139FK Comparator Differential Open-Collector, Open-Drain, Rail-to-Rail 20-LCCC
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | LM139FK |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Type: | Differential | Number Of Elements: | 4 |
|---|---|---|---|
| Output Type: | Open-Collector, Open-Drain, Rail-to-Rail | Voltage - Supply, Single/Dual (±): | 2V ~ 30V, ±1V ~ 15V |
| Voltage - Input Offset (Max): | 5mV @ 5V | Current - Input Bias (Max): | 0.1µA @ 5V |
| Current - Output (Typ): | 16mA @ 5V | Current - Quiescent (Max): | 2mA |
Product Description
LM139FK Comparator Differential Open-Collector, Open-Drain, Rail-to-Rail 20-LCCC
Specifications of LM139FK
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Linear | |
| Comparators | |
| Mfr | Texas Instruments |
| Series | - |
| Package | Tube |
| Type | Differential |
| Number of Elements | 4 |
| Output Type | Open-Collector, Open-Drain, Rail-to-Rail |
| Voltage - Supply, Single/Dual (±) | 2V ~ 30V, ±1V ~ 15V |
| Voltage - Input Offset (Max) | 5mV @ 5V |
| Current - Input Bias (Max) | 0.1µA @ 5V |
| Current - Output (Typ) | 16mA @ 5V |
| Current - Quiescent (Max) | 2mA |
| CMRR, PSRR (Typ) | - |
| Propagation Delay (Max) | 300ns (Typ) |
| Hysteresis | - |
| Operating Temperature | -55°C ~ 125°C |
| Package / Case | 20-CLCC |
| Mounting Type | Surface Mount |
| Supplier Device Package | 20-LCCC (8.89x8.89) |
Features of LM139FK
• Wide Supply Ranges
– Single Supply: 2 V to 36 V (Tested to 30 V)
– Dual Supplies: ±1 V to ±18 V (Tested to ±15 V)
• Low Supply-Current Drain Independent of Supply Voltage: 0.8 mA (Typical)
• Low Input Bias Current: 25 nA (Typical)
• Low Input Offset Current: 3 nA (Typical)
• Low Input Offset Voltage: 2 mV (Typical)
• Common-Mode Input Voltage Range Includes Ground
• Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage: ±36 V
• Low Output Saturation Voltage
• Output Compatible With TTL, MOS, and CMOS
• On Products Compliant to MIL-PRF-38535, All Parameters Are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Necessarily Include Testing of All Parameters.
Applications of LM139FK
• Industrial
• Automotive
– Infotainment and Clusters
– Body Control Modules
• Power Supervision
• Oscillators
• Peak Detectors
• Logic Voltage Translation
Environmental & Export Classifications of LM139FK
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| ECCN | EAR99 |
| HTSUS | 8542.33.0001 |
