CM453232-101KL 100 µH Unshielded Drum Core Wirewound Inductor 110 mA 8Ohm
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | CM453232-101KL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Material - Core: | Ferrite | Inductance: | 100 µH |
|---|---|---|---|
| Tolerance: | ±10% | Current Rating (Amps): | 110 MA |
| Shielding: | Unshielded | DC Resistance (DCR): | 8Ohm Max |
| Q @ Freq: | 40 @ 796kHz | Frequency - Self Resonant: | 8MHz |
Product Description
CM453232-101KL 100 µH Unshielded Drum Core Wirewound Inductor 110 mA 8Ohm
Specifications of CM453232-101KL
| TYPE | DESCRIPTION |
| Category | Inductors, Coils, Chokes |
| Fixed Inductors | |
| Mfr | Bourns Inc. |
| Series | CM45 |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 100 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 110 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 8Ohm Max |
| Q @ Freq | 40 @ 796kHz |
| Frequency - Self Resonant | 8MHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 2.52 MHz |
| Mounting Type | Surface Mount |
| Package / Case | 1812 (4532 Metric) |
| Supplier Device Package | 1812 |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) |
| Height - Seated (Max) | 0.134" (3.40mm) |
| Base Product Number | CM453232 |
Features of CM453232-101KL
* High resistance to heat and humidity
* Resistance to mechanical shock and pressure
* Accurate dimensions for automatic surface mounting
* Wide inductance range (1.0 nH to 1000 µH)
* RoHS compliant*
Descriptions of CM453232-101KL
Temperature Rise 20 ˚C max.
Ambient Temperature 100 ˚C max.
Operating Temperature -40 °C to +125 °C
Storage Temperature -40 °C to +125 °C
Resistance to Soldering Heat 260 ˚C, 5 seconds
Environmental & Export Classifications of CM453232-101KL
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8504.50.8000 |
