SN74LVC1G08MDCKREP Integrated Circuit Chip AND Gate IC 1 Channel SC-70-5
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SN74LVC1G08MDCKREP |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 3-5ddays |
| Payment Terms: | T/T |
| Supply Ability: | 1000 |
|
Detail Information |
|||
| Logic Type: | AND Gate | Number Of Circuits: | 1 |
|---|---|---|---|
| Number Of Inputs: | 2 | Voltage - Supply: | 1.65V ~ 5.5V |
| Current - Quiescent (Max): | 10 µA | Current - Output High, Low: | 32mA, 32mA |
| Max Propagation Delay @ V, Max CL: | 5ns @ 5V, 50pF | Operating Temperature: | -55°C ~ 125°C |
Product Description
SN74LVC1G08MDCKREP Integrated Circuit Chip AND Gate IC 1 Channel SC-70-5
Specifications of SN74LVC1G08MDCKREP
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Gates and Inverters | |
| Mfr | Texas Instruments |
| Series | 74LVC |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Product Status | Active |
| Logic Type | AND Gate |
| Number of Circuits | 1 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 1.65V ~ 5.5V |
| Current - Quiescent (Max) | 10 µA |
| Current - Output High, Low | 32mA, 32mA |
| Input Logic Level - Low | - |
| Input Logic Level - High | - |
| Max Propagation Delay @ V, Max CL | 5ns @ 5V, 50pF |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | SC-70-5 |
| Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
| Base Product Number | 74LVC1G08 |
Features of SN74LVC1G08MDCKREP
* Controlled Baseline
- One Assembly/Test Site, One FabricationSite
* Extended Temperature Performance of -55°Cto 125°C
* Enhanced Diminishing ManufacturingSources (DMS) Support
* Enhanced Product-Change NotificationQualification Pedigree (1) of Supports Partial-Power-Down ModeOperation
* Latch-Up Performance Exceeds 100 mA PerJESD 78, Class Il
* ESD Protection Exceeds JESD 22
- 2000-V Human-Body Model(A114-A)
- 200-V Machine Model(A115-A)
- 1000-V Charged-Device Model (C101)
Applications of SN74LVC1G08MDCKREP
The SN74LVC1G08 performs the Boolean function Y A • B or Y A B in positive logic.
Environmental & Export Classifications of SN74LVC1G08MDCKREP
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
