SI1010-C-GM2R IC RF TxRx + MCU General ISM < 1GHz EZRadioPro 240MHz ~ 960MHz
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SBR40U200CTB-13 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 3-5ddays |
| Payment Terms: | T/T |
| Supply Ability: | 1000 |
|
Detail Information |
|||
| Type: | TxRx + MCU | RF Family/Standard: | General ISM < 1GHz |
|---|---|---|---|
| Protocol: | EZRadioPro | Modulation: | FSK, GFSK, OOK |
| Frequency: | 240MHz ~ 960MHz | Data Rate (Max): | 256kbps |
| Power - Output: | 20dBm | Sensitivity: | -121dBm |
Product Description
SI1010-C-GM2R IC RF TxRx + MCU General ISM < 1GHz EZRadioPro 240MHz ~ 960MHz
Specifications of SI1010-C-GM2R
| TYPE | DESCRIPTION |
| Category | RF and Wireless |
| RF Transceiver ICs | |
| Mfr | Silicon Labs |
| Series | - |
| Package | Tape & Reel (TR) |
| Product Status | Not For New Designs |
| Type | TxRx + MCU |
| RF Family/Standard | General ISM < 1GHz |
| Protocol | EZRadioPro |
| Modulation | FSK, GFSK, OOK |
| Frequency | 240MHz ~ 960MHz |
| Data Rate (Max) | 256kbps |
| Power - Output | 20dBm |
| Sensitivity | -121dBm |
| Memory Size | 16kB Flash, 768B RAM |
| Serial Interfaces | I²C, SPI, UART |
| GPIO | 15 |
| Voltage - Supply | 1.8V ~ 3.6V |
| Current - Receiving | 18.5mA |
| Current - Transmitting | 85mA |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 42-VFLGA Exposed Pad |
| Supplier Device Package | 42-LGA (5x7) |
| Base Product Number | SI1010 |
Features of SI1010-C-GM2R
The Si1010/1/2/3/4/5 SoC family includes several key enhancements to the CIP-51 core and peripherals to improve performance and ease of use in end applications
Applications of SI1010-C-GM2R
Si1010/1/2/3/4/5 devices are fully integrated mixed-signal System-on-a-Chip MCUs. Highlighted features are listed below. Refer to Table 2.1 for specific product feature selection and part ordering numbers.
Environmental & Export Classifications of SI1010-C-GM2R
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | RoHS Compliant |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) |
| ECCN | EAR99 |
| HTSUS | 8542.31.0001 |
