SN74LVC16373ADGGR Latch IC With 2 Channel 8:8 Tri-State 48-TSSOP Transparent
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SN74LVC16373ADGGR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 3-5ddays |
| Payment Terms: | T/T |
| Supply Ability: | 1000 |
|
Detail Information |
|||
| Logic Type: | D-Type Transparent Latch | Circuit: | 8:08 |
|---|---|---|---|
| Output Type: | Tri-State | Voltage - Supply: | 1.65V ~ 3.6V |
| Independent Circuits: | 2 | Delay Time - Propagation: | 2.1ns |
| Current - Output High, Low: | 24mA, 24mA | Operating Temperature: | -40°C ~ 85°C |
Product Description
SN74LVC16373ADGGR Latch IC With 2 Channel 8:8 Tri-State 48-TSSOP Transparent
IC TRANS D-TYP LATCH 3ST 48TSSOP
Specifications of SN74LVC16373ADGGR
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Latches | |
| Mfr | Texas Instruments |
| Series | 74LVC |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Product Status | Active |
| Logic Type | D-Type Transparent Latch |
| Circuit | 8:08 |
| Output Type | Tri-State |
| Voltage - Supply | 1.65V ~ 3.6V |
| Independent Circuits | 2 |
| Delay Time - Propagation | 2.1ns |
| Current - Output High, Low | 24mA, 24mA |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 48-TFSOP (0.240", 6.10mm Width) |
| Supplier Device Package | 48-TSSOP |
| Base Product Number | 74LVC16373 |
Features of SN74LVC16373ADGGR
* Member of the Texas Instruments Widebus 7 Family
* Operates From 1.65 V to 3.6 V
* Inputs Accept Voltages to 5.5 V
* Max tpd of 4.2 ns at 3.3 V
* Typical VoLP (Output Ground Bounce)<0.8 V at Vcc = 3.3 V, TA = 25C
* Typical Vohv (Output Vo Undershoot)>2 V at Vcc = 3.3 V, TA = 25'C
* loff Supports Live-lnsertion, Partial-Power-DownMode, and Back-Drive Protection
* Supports Mixed-Mode Signal Operation (5-V Inputand Output Voltages With 3.3-V Vcc)
* Latch-Up Performance Exceeds 100 mA PerJESD 78, Class Il
* ESD Protection Exceeds JESD
- 222000-V Human-Body Model (A114-A)
- 1000-V Charged-Device Model (C101)
Applications of SN74LVC16373ADGGR
* Servers
* PCs and Notebooks
* Network Switches
* Wearable Health and Fitness Devices
* Telecom Infrastructures
* Electronic Points of Sale
Environmental & Export Classifications of SN74LVC16373ADGGR
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
