SNJ54LVC14AJ Integrated Circuits IC 6 Channel Schmitt Trigger IC 14CDIP
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | SNJ54LVC14AJ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Logic Type: | Inverter | Number Of Circuits: | 6 |
|---|---|---|---|
| Number Of Inputs: | 6 | Features Schmitt: | Trigger |
| Voltage - Supply: | 2V ~ 3.6V | Current - Quiescent (Max): | 1 µA |
| Current - Output High, Low: | 24mA, 24mA | Input Logic Level - High: | 1.3V ~ 2V |
| Max Propagation Delay @ V, Max CL: | 6.2ns @ 3.3V, 50pF | Operating Temperature: | -55°C ~ 125°C |
| Highlight: | SNJ54LVC14AJ Integrated Circuits,6 Channel Schmitt Trigger IC,14CDIP Schmitt Trigger ic |
||
Product Description
SNJ54LVC14AJ Integrated Circuits IC Chip 6 Channel Schmitt Trigger 14-CDIP
MILITARY 6-CH, 2-V TO 3.6-V INVE
Specifications of SNJ54LVC14AJ
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Gates and Inverters | |
| Mfr | Texas Instruments |
| Series | 54LVC |
| Package | Tube |
| Product Status | Active |
| Logic Type | Inverter |
| Number of Circuits | 6 |
| Number of Inputs | 6 |
| Features | Schmitt Trigger |
| Voltage - Supply | 2V ~ 3.6V |
| Current - Quiescent (Max) | 1 µA |
| Current - Output High, Low | 24mA, 24mA |
| Input Logic Level - High | 1.3V ~ 2V |
| Max Propagation Delay @ V, Max CL | 6.2ns @ 3.3V, 50pF |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Supplier Device Package | 14-CDIP |
| Package / Case | 14-CDIP (0.300", 7.62mm) |
Features of SNJ54LVC14AJ
• Latch-up performance exceeds 100 mA per JESD 78, Class II
• ESD protection exceeds JESD 22
– 2000-V human-body model (A114-A)
– 200-V machine model (A115-A)
– 1000-V charged-device model (C101)
• Operate from 1.65 V to 3.6 V VCC
• Specified from –40°C to +85°C,
–40°C to 125°C, and –55°C to 125°C
• Inputs accept voltages to 5.5 V
• Max tpd of 6.4 ns at 3.3 V
• Typical VOLP (output ground bounce)
<0.8 V at VCC = 3.3 V, TA = 25°C
• Typical VOHV (output VOH undershoot)
>2 V at VCC = 3.3 V, TA = 25°C
• On products compliant to MIL-PRF-38535,
all parameters are tested unless otherwise noted.
On all other products, production processing does not necessarily include testing of all parameters.
Applications of SNJ54LVC14AJ
• Barcode scanner
• Cable solutions
• E-books
• Embedded PCs
• Field transmitter: temperature or pressure sensors
• Fingerprint biometrics
• HVAC: heating, ventilating, and air conditioning
• Network attached storage (NAS)
• Server motherboard and PSU
• Software defined radio (SDR)
• TV: High-definition (HDTV), LCD, and digital
• Video communications systems
• Wireless data access cards, headsets, keyboards, mice, and LAN cards
Environmental & Export Classifications of SNJ54LVC14AJ
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | Not Applicable |
