DBL1010HB-100M-R Integrated Circuit Chip 7-18V 1KHZ Low Noise
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | DBL1010HB-100M-R |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Diode Configuration: | 1 Pair Common Cathode | Technology: | Schottky |
|---|---|---|---|
| Voltage - DC Reverse (Vr) (Max): | 170 V | Current - Average Rectified (Io) (per Diode): | 8A |
| Voltage - Forward (Vf) (Max) @ If: | 920 MV @ 8 A | Speed: | Fast Recovery =< 500ns, > 200mA (Io) |
| Current - Reverse Leakage @ Vr: | 15 µA @ 170 V | Operating Temperature - Junction: | 175°C (Max) |
Product Description
DBL1010HB-100M-R Integrated Circuit Chip 7-18V 1KHZ Low Noise
Unless otherwise specified, Vcc=10V, f=1KHz, Rg=600, RL=10K. Ta=25°C
Specifications of DBL1010HB-100M-R
(Unless otherwise specified, Vcc=10V, f=1KHz, Rg=600, RL=10K. Ta=25°C)
| Characteristics | symbol | Test circuit | Test Conditions | mine | type | maximum | unit |
| Quiescent Current | ICCO | 1 | - | 5.5 | 8.5 | mA | |
| Open loop voltage gain | GVO | 1 | Cf=100μF, Rf=0 | - | 100 | - | dB |
| Equivalent input | VOM | 2 |
THD 0.5%, NAB equalization |
2 | 2.8 | Vrms | |
| noise voltage | VNI | 2 | Rg=2.2kΩ BPF15HZ-30kHz | - | 1 | 2.5 | µVrms |
| input resistance | RIN | 2 | Vo=1Vrms | - | 100 | - | kΩ |
| channel separation | CHSEP | 2 | f=10kHz, Rg 2.2kΩ Vo=1Vrms |
- | 70 | - | dB |
| Ripple rejection | R.R. | 2 | f=100Hz, VIN=1Vrms CB connectionless |
- | 50 | - | dB |
| Muting ratio | M.R. | 2 | Vg=1V, OdB 1 Vrms. | 80 | - | dB |
Features of DBL1010HB-100M-R
* High Voltage Gain: Gvo 100dB (Typ) at f=1kHz
* Excellent channel separation and high ripple
rejection: CHSEP. 70dB (Typ)
R.R.=50dB(Typ.)
* Low Noise: VNI = 1.0μVrms (Typ)
At Rg 2.2k.Ω = 15Hz-30kHz
* Muting circuit built-in: 2V≧V9≧0.9V
* Wide operating supply voltage range: Vcc = 7-18V.
* Excellent channel separation and high ripple
rejection: CHSEP. 70dB (Typ)
R.R.=50dB(Typ.)
* Low Noise: VNI = 1.0μVrms (Typ)
At Rg 2.2k.Ω = 15Hz-30kHz
* Muting circuit built-in: 2V≧V9≧0.9V
* Wide operating supply voltage range: Vcc = 7-18V.
Applications of DBL1010HB-100M-R
* Car or home stereo use.
* DBL 1010 is 8 SIP, Pin9 (Function: Muteing) cut.
Want to Know more details about this product
