VNH5180ATR-E Temperature Sensor Chip MOSFET Parallel PWM PowerSSO-36 TP
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | VNH5180ATR-E |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Interface: | Parallel, PWM | Technology: | Power MOSFET |
|---|---|---|---|
| Step Resolution: | - | Applications: | Automotive |
| Current - Output: | 8A | Voltage - Supply: | 5.5V ~ 18V |
| Voltage - Load: | 5.5V ~ 18V | Operating Temperature: | -40°C ~ 150°C (TJ) |
Product Description
VNH5180ATR-E Temperature Sensor Chip MOSFET Parallel PWM PowerSSO-36 TP
IC MTR DRVR 5.5V-18V 36POWERSSO
Specifications of VNH5180ATR-E
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Motor Drivers, Controllers | |
| Mfr | STMicroelectronics |
| Series | ECOPACK®, VIPower™ |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Product Status | Active |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushed DC |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (2) |
| Interface | Parallel, PWM |
| Technology | Power MOSFET |
| Step Resolution | - |
| Applications | Automotive |
| Current - Output | 8A |
| Voltage - Supply | 5.5V ~ 18V |
| Voltage - Load | 5.5V ~ 18V |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 36-PowerBFSOP (0.295", 7.50mm Width) |
| Supplier Device Package | PowerSSO-36 TP |
| Base Product Number | VNH5180 |
Features of VNH5180ATR-E
• Output current: 8 A
• 3 V CMOS compatible inputs
• Undervoltage shutdown
• Overvoltage clamp
• Thermal shutdown
• Cross-conduction protection
• Current and power limitation
• Very low standby power consumption
• PWM operation up to 20 KHz
• Protection against loss of ground and loss of VCC
• Current sense output proportional to motor current
• Output protected against short to ground and short to VCC
• Package: ECOPACK®
• 3 V CMOS compatible inputs
• Undervoltage shutdown
• Overvoltage clamp
• Thermal shutdown
• Cross-conduction protection
• Current and power limitation
• Very low standby power consumption
• PWM operation up to 20 KHz
• Protection against loss of ground and loss of VCC
• Current sense output proportional to motor current
• Output protected against short to ground and short to VCC
• Package: ECOPACK®
Description of VNH5180ATR-E
The VNH5180A-E is a full bridge motor driver intended for a wide range of automotive
applications. The device incorporates a dual monolithic high-side driver and two low-side switches.
Environmental & Export Classifications of VNH5180ATR-E
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
