LMH1208RTVR 32-WQFN Video Driver IC Serial AES10 DVB-ASI SMPTE
Product Details:
| Place of Origin: | Original |
| Brand Name: | TI |
| Certification: | Original |
| Model Number: | LMH1208RTVR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Part No: | LMH1208RTVR | Standards: | AES10, DVB-ASI, SMPTE |
|---|---|---|---|
| Voltage - Supply: | 2.375V ~ 2.625V | Single Supply: | 2.5-V |
| Mounting Type: | Surface Mount | Power Consumption: | 25 MW (Typical) |
| Operating Temperature: | −40°C To 85°C | ||
| Highlight: | LMH1208RTVR,32-WQFN Video Driver IC,AES10 DVB-ASI SMPTE |
||
Product Description
LMH1208RTVR Video Driver IC Serial AES10 DVB-ASI SMPTE 32-WQFN
Video Driver IC Serial AES10, DVB-ASI, SMPTE 32-WQFN (5x5) Package
LMH1208 device is a 12G UHD-SDI low power dual output cable driver. It supports SMPTE video rates up to 11.88 Gbps, enabling UHD video for 4K/8K applications. The additional equalized 100-Ω driver output on the host-side can be used for monitoring or signal distribution purposes.
Specifications of LMH1208RTVR
|
TYPE
|
DESCRIPTION
|
|---|---|
|
Category
|
Integrated Circuits (ICs)
Linear
Video Processing
|
|
Mfr
|
Texas Instruments
|
|
Series
|
-
|
| Package | tape and reel |
|
Product Status
|
Active
|
|
Function
|
Driver
|
|
Applications
|
Professional Video
|
|
Standards
|
AES10, DVB-ASI, SMPTE
|
|
Control Interface
|
Serial
|
|
Voltage - Supply
|
2.375V ~ 2.625V
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
32-WFQFN Exposed Pad
|
|
Supplier Device Package
|
32-WQFN (5x5)
|
|
Base Product Number
|
LMH1208
|
Features of LMH1208RTVR
• Supports ST-2082-1 (12G), ST-2081-1 (6G), ST424 (3G), ST-292 (HD), and ST-259 (SD)
• Compatible with DVB-ASI and AES10 (MADI)
• Dual differential output cable drivers
• On-chip 75-Ω termination and return loss compensation network
• Host-side equalized 100-Ω loop-back output
• Programmable slew rate control on 75-Ω outputs
• Programmable pre-emphasis and output amplitude on 75-Ω outputs
• Programmable de-emphasis and output amplitude on 100-Ω output
• Polarity inversion on 75-Ω and 100-Ω outputs
• Automatic power save in absence of input signal
– Power consumption: 25 mW (Typical)
• Power-down control through ENABLE pin
• Single 2.5-V supply
– Power consumption: 200 mW (typical)
• Programmable through pins, SPI, or SMBus interface
• –40°C to +85°C operating temperature range
• 5-mm × 5-mm, 32-pin WQFN package
range (−10 ̊
Environmental & Export Classifications
with avck-
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
APPLICATIONS of LMH1208RTVR
• SMPTE compatible serial digital interface
• UHDTV/4K/8K/HDTV/SDTV video
• IP media gateway
• Digital video processing and editing
